IBM System x3250 M4 21
Storage host bus adapters
The following table lists the storage host bus adapters (HBAs) supported by x3250 M4 server.
Table 10. Storage adapters
Part number Feature
code
Description Maximum
supported
Fibre Channel
81Y1655 A2W5 Emulex 16Gb FC Single-port HBA for IBM System x 1
81Y1662 A2W6 Emulex 16Gb FC Dual-port HBA for IBM System x 1
81Y1668 A2XU Brocade 16Gb FC Single-port HBA for IBM System x 1
81Y1675 A2XV Brocade 16Gb FC Dual-port HBA for IBM System x 1
00Y3337 A3KW QLogic 16Gb FC Single-port HBA for IBM System x 1
00Y3341 A3KX QLogic 16Gb FC Dual-port HBA for IBM System x 1
46M6049 3589 Brocade 8 Gb FC Single-port HBA for IBM System x 1
46M6050 3591 Brocade 8 Gb FC Dual-port HBA for IBM System x 1
42D0485 3580 Emulex 8 Gb FC Single-port HBA for IBM System x 1
42D0494 3581 Emulex 8 Gb FC Dual-port HBA for IBM System x 1
42D0501 3578 QLogic 8 Gb FC Single-port HBA for IBM System x 1
42D0510 3579 QLogic 8 Gb FC Dual-port HBA for IBM System x 1
Converged Network Adapters (CNA)
42C1820 1637 Brocade 10 Gb Dual-port CNA for IBM System x 1
42C1800 5751 QLogic 10 Gb Dual Port CNA for IBM System x 1
SAS
46M0907 5982 IBM 6 Gb SAS HBA Controller 1
For more information, see the list of IBM Redbooks Product Guides in the Host bus adapters category:
http://www.redbooks.ibm.com/portals/systemx?Open&page=pg&cat=hba
PCIe SSD adapters
The server does not support the High IOPS SSD adapters.

IBM x3250 M4 Specifications

General

Form Factor	1U Rack
Max Processors	1
Memory	Up to 32 GB DDR3
Memory Slots	4 DIMM slots
Processor	Intel Xeon E3-1200 v2 series
Chipset	Intel C202
Storage	SATA/SAS
Hard Drive Bays	4x 3.5" or 8x 2.5"
RAID Support	RAID 0, 1, 10
Network	2x Gigabit Ethernet
Power Supply	350W
Expansion Slots	1x PCIe 3.0 x8
Operating System Support	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
