IBM System x3250 M4 15
Table 6. Disk drive options (Part 3)
Part number Feature
code
Description Maximum
supported
2.5" Hot-swap SSDs - Enterprise Value
49Y5839 A3AS IBM 64GB SATA 2.5" MLC HS Enterprise Value SSD 4
90Y8648 A2U4 IBM 128GB SATA 2.5" MLC HS Enterprise Value SSD 4
90Y8643 A2U3 IBM 256GB SATA 2.5" MLC HS Enterprise Value SSD 4
49Y5844 A3AU IBM 512GB SATA 2.5" MLC HS Enterprise Value SSD 4
2.5" Hot-swap SSDs - Enterprise
00W1125 A3HR IBM 100GB SATA 2.5" MLC HS Enterprise SSD 4
49Y6139 A3F0 IBM 800GB SAS 2.5" MLC HS Enterprise SSD 4
49Y6134 A3EY IBM 400GB SAS 2.5" MLC HS Enterprise SSD 4
49Y6129 A3EW IBM 200GB SAS 2.5" MLC HS Enterprise SSD 4
The following table lists the RAID controllers and additional options used for internal disk storage of x3250
M4 server.
Table 7. RAID controllers for internal storage
Part number Feature
code
Description Maximum
supported
Standard models
where used
Integrated None ServeRAID C100 for System x 1 32x, 42x, 62x, A2x,
B2x
49Y4731 9742 ServeRAID-BR10il SAS/SATA Controller v2 1 72x
81Y4492 A1XL ServeRAID H1110 SAS/SATA Controller 1 C2x, F2x
46M0831 0095 ServeRAID M1015 SAS/SATA Controller 1 -
46M0832 9749 ServeRAID M1000 Series Advance Feature
Key
1 -
46M0916 3877 ServeRAID M5014 SAS/SATA Controller 1 -
46M0829 0093 ServeRAID M5015 SAS/SATA Controller 1 -
The ServeRAID C100 is an integrated SATA controller with software RAID capabilities. It is a
cost-effective way to provide reliability, performance, and fault-tolerant disk subsystem management to
help safeguard your valuable data and enhance availability. The ServeRAID C100 has the following
specifications:
Onboard SATA controller with software RAID capabilities
Supports 3 Gbps SATA ports
RAID levels 0, 1, and 10 support
Support for up to two virtual drives
Support for virtual drive sizes greater than 2 TB
Fixed stripe unit size of 64 KB
Support for MegaRAID Storage Manager management software
