Release latch
Power supply
4. If you are instructed to return the hot-swap power supply, follow all packaging
instructions, and use any packaging materials for shipping that are supplied to
you.
5. Touch the static-protective package that contains the hot-swap power supply to
any unpainted metal surface on the server; then, remove the power supply
from the package and place it on a static-protective surface.
6. Place the power supply into the bay guides.
Power supply filler
Release latch
Power supply
7. Press down on the orange release lever and push the power supply toward the
front of the chassis until it locks into place.
8. Connect one end of the power cord into the connector on the back of the
power supply and connect the other end of the power cord into a properly
grounded electrical outlet.
54 System x3400 Types 7973, 7974, 7975, and 7976: User’s Guide
