IBM X3850 X6 Product Guide

IBM System x3850 X6 31
PCIe SSD adapters
The server supports the High IOPS SSD adapters that are listed in the following table. The maximum
quantity listed is for configurations with all processors and I/O books installed.
Table 16. SSD adapters
Part number Feature code Description Maximum
supported
x3850 X6
46C9078 A3J3 IBM 365GB High IOPS MLC Mono Adapter 9
46C9081 A3J4 IBM 785GB High IOPS MLC Mono Adapter 9
90Y4377 A3DY IBM 1.2TB High IOPS MLC Mono Adapter 9
90Y4397 A3DZ IBM 2.4TB High IOPS MLC Duo Adapter 9
For more information about these adapters, see the IBM Redbooks Product Guide IBM High IOPS MLC
Adapters , TIPS0907, found at the following address:
http://www.redbooks.ibm.com/abstracts/tips0907.html?Open
GPU adapters and co-processors
The server supports the co-processors and graphics processing units (GPUs) that are listed in the
following table. Each is installed in a Full-length I/O Book. No other adapter can be installed in the
Full-length I/O Book. The Full-length I/O Book includes the necessary auxiliary power cables.
Note: These adapters are not available through CTO and cannot be shipped installed in the server
because they are installed in the Full-length I/O Book, which extends beyond the rear of the chassis (see
Figure 12). These adapters must be shipped separately from the server. Order the adapter and
Full-length I/O Book as separate options.
Table 17. GPU adapters
Part
number*
Feature
code
Description Minimu
m
system
RAM
Maximu
m
supporte
d
x3850 X6
00FP670 A4G4* Intel Xeon Phi 3120A PCIe x16 for System x3850/x3950 X6 12 GB 2
00FP671 A5U2* NVIDIA Grid K1 PCIe x16 for System x3850/x3950 X6 32 GB 2
00FP674 A470* NVIDIA Grid K2 Actively Cooled PCIe x16 for System
x3850/x3950 X6
16 GB 2
00FP673 A471* NVIDIA Tesla K20 Actively Cooled PCIe x16 for System
x3850/x3950 X6
10 GB 2
00FP676 A5FG* NVIDIA Tesla K40c PCIe x16 for System x3850/x3950 X6 24 GB 2
00FP675 A3YU* NVIDIA Quadro K4000 PCIe x16 for System x3850/x3950 X6 6 GB 2
00FP672 A3YV* NVIDIA Quadro K6000 PCIe x16 for System x3850/x3950 X6 24 GB 2
* Not available through CTO.

IBM X3850 X6 Specifications

General

Chipset	Intel C602J
Network Controller	Integrated quad-port Gigabit Ethernet
Processor	Up to four Intel Xeon E7-4800 v2 series processors or Intel Xeon E7-8800 v2 series processors
Memory	Up to 6 TB of DDR3 ECC Registered DIMMs (RDIMMs) or Load-Reduced DIMMs (LRDIMMs)
Form Factor	4U rack server
Storage	Up to 24x 2.5" hot-swap SAS/SATA HDDs or SSDs
Expansion Slots	Up to 11 PCIe 3.0 slots
Power Supply	Up to four 1400W or 900W hot-swap power supplies
Memory Type	DDR3 RDIMM/LRDIMM
Storage Controller	ServeRAID M5210 SAS/SATA controller
RAID Support	RAID 0, 1, 5, 6, 10, 50, 60
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
