External disk storage expansion
The server supports attachment to external storage expansion enclosures, such as the EXP2500 series,
by using the ServeRAID M5120 SAS/SATA Controller. The server can also be attached to supported
external storage systems, such as the IBM System Storage® DS3500 series, by using a supported HBA
(see the earlier "Storage HBA" section). The following table shows the RAID controllers and options for
external disk storage expansion.
Table 21. RAID controllers and options for external disk storage expansion
Part number Feature
code
Description Maximum
supported
x3850 X6
Standard models
where used
81Y4478 A1WX ServeRAID M5120 SAS/SATA Controller 2 -
Hardware upgrades for the M5120
81Y4487 A1J4 ServeRAID M5100 Series 512MB Flash/RAID 5
Upgrade
1 -
81Y4559 A1WY ServeRAID M5100 Series 1GB Flash/RAID 5 Upgrade 1 -
Feature on Demand upgrades for the M5120
90Y4318 A2MD ServeRAID M5100 Series SSD Caching Enabler 1* -
90Y4273 A2MC ServeRAID M5100 Series SSD Performance Key 1* -
81Y4546 A1X3 ServeRAID M5100 Series RAID 6 Upgrade 1* -
* These M5120 features upgrades require a cache memory upgrade (81Y4487 or 81Y4559).
The ServeRAID M5120 SAS/SATA Controller has the following specifications:
Eight external 6 Gbps SAS/SATA ports

Up to 6 Gbps throughput per port

Two external x4 mini-SAS connectors (SFF-8088)

Supports RAID 0, 1, and 10

Supports RAID 5 and 50 with optional M5100 Series RAID 5 upgrades

Supports RAID 6 and 60 with the optional M5100 Series RAID 6 upgrade

Supports 512 MB or 1 GB flash-backed cache

PCIe 3.0 x8 host interface

Based on the LSI SAS2208 6 Gbps ROC controller

Supports connectivity to the EXP2512 and EXP2524 storage expansion enclosures

For more information, see the IBM Redbooks Product Guide ServeRAID M5120 SAS/SATA Controller for
IBM System x , TIPS0858, found at the following website:
http://www.redbooks.ibm.com/abstracts/tips0858.html?Open

IBM X3850 X6 Specifications

General

Chipset	Intel C602J
Network Controller	Integrated quad-port Gigabit Ethernet
Processor	Up to four Intel Xeon E7-4800 v2 series processors or Intel Xeon E7-8800 v2 series processors
Memory	Up to 6 TB of DDR3 ECC Registered DIMMs (RDIMMs) or Load-Reduced DIMMs (LRDIMMs)
Form Factor	4U rack server
Storage	Up to 24x 2.5" hot-swap SAS/SATA HDDs or SSDs
Expansion Slots	Up to 11 PCIe 3.0 slots
Power Supply	Up to four 1400W or 900W hot-swap power supplies
Memory Type	DDR3 RDIMM/LRDIMM
Storage Controller	ServeRAID M5210 SAS/SATA controller
RAID Support	RAID 0, 1, 5, 6, 10, 50, 60
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
