IBM X3850 X6 Product Guide

IBM System x3850 X6 7
Table 1. Standard specifications (Part 2)
Components Specification
Power supply Up to four redundant hot-swap 900 W AC or 1400 W AC power supplies (all 80 PLUS Platinum
certified). -48 V 750 W DC power supplies are available through CTO. Power supplies cannot
be mixed.
Hot-swap parts Drives, power supplies, fans, and optional I/O Books.
Video Matrox G200eR2 with 16 MB memory that is integrated into the IMM2. Maximum resolution is
1600 x 1200 at 75 Hz with 16 M colors.
Security
features
Power-on password, admin password, and two Trusted Platform Modules (TPMs).
Systems
management
UEFI, IBM Integrated Management Module II (IMM2) with remote presence feature, Predictive
Failure Analysis, Light Path Diagnostics, Automatic Server Restart, IBM Systems Director and
Active Energy Manager™, and IBM ServerGuide.
Operating
systems
supported
Microsoft Windows Server 2012 R2, 2012, and 2008 R2, Red Hat Enterprise Linux 6, SUSE
Linux Enterprise Server 11, and VMware vSphere ESXi 5.1 and 5.5.
Limited
warranty
Three-year customer-replaceable unit (CRU) and onsite limited warranty with 9x5 next business
day (NBD).
Service and
support
Optional service upgrades are available through IBM ServicePac® offerings: 4-hour or 2-hour
response time, 8-hour fix time, 1-year or 2-year warranty extension, and remote technical
support for IBM hardware and some IBM / OEM applications.
Dimensions Height: 173 mm (6.8 in.), width: 482 mm (19.0 in.), depth: 804 mm (31.6 in.), depth with
Full-length I/O Book installed: 903 mm (35.5 in.).
Weight Minimum configuration: 35.9 kg (79.2 lb), typical: 46.4 kg (102.3 lb), maximum: 54.7 kg (120 lb)
The server is shipped with the following items:
Statement of Limited Warranty

Important Notices

Rack Installation Instructions

Documentation CD that contains the Installation and Service Guide

IBM Systems Director Flyer

IBM System x® Rail Kit

2.8 m (9.18 ft) C13-C14 power cord (one for each power supply)


IBM X3850 X6 Specifications

General

Chipset	Intel C602J
Network Controller	Integrated quad-port Gigabit Ethernet
Processor	Up to four Intel Xeon E7-4800 v2 series processors or Intel Xeon E7-8800 v2 series processors
Memory	Up to 6 TB of DDR3 ECC Registered DIMMs (RDIMMs) or Load-Reduced DIMMs (LRDIMMs)
Form Factor	4U rack server
Storage	Up to 24x 2.5" hot-swap SAS/SATA HDDs or SSDs
Expansion Slots	Up to 11 PCIe 3.0 slots
Power Supply	Up to four 1400W or 900W hot-swap power supplies
Memory Type	DDR3 RDIMM/LRDIMM
Storage Controller	ServeRAID M5210 SAS/SATA controller
RAID Support	RAID 0, 1, 5, 6, 10, 50, 60
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
