Operation

EconomyMode

TheEconomymodeprovidesatransmissionshiftschedulefor

improvedfueleconomy.T oactivatethismode,switchtheECON

/ONswitch,ontherightswitchpanel,totheONposition.When

intheONpositiontheswitchindicatorwillbeturnedon.

AutomaticTransmissionOperatingTemperatures

Yourvehiclemaybeequippedwithawarningindicatororgauge

thatwillindicatehightransmissionuidtemperatures.

Thesump/uidreservoirtemperaturesoftheAllison

Transmissionsshouldnotexceed250°F(120°C)

131
