iCarsoft MB II - 3 Product Descriptions; Outline of Icarsoft Serial Products; CR Plus

iCarsoft English User’s Manual
5
3. Product Descriptions
3.1 Outline of iCarsoft Serial products / CR Plus
Figure 2-1
1
OBD-16 Connector
Connects the iCarsoft Serial products / CR
Plus to the vehicle’s Data Link Connector
(DLC) via the diagnostic cable.
2
▲/▼Button
Move cursor up or down for selection.
►/◄ Button
Move cursor right or left for selection; Or
turn page up or down when more than one
page is displayed.
3
OK Button
Confirms a selection (or action) from a menu
list.
4
ESC Button
Exit the current program or return to the
