ICE Games SNACK ATTACK - Page 26

26
D C
B A
4321
D C
B A
4321
DATE
7/9/01
DESCRIPTION
#CS2050X - DOOR HARNESS
DRAWN BY
MMARTIN
FILENAME
CS.VSD
PAGE
3 OF 16
REVISED
2/6/02
TITLE
SNACK ATTACKER
1 2 3 4 5 6 7 8 9
10 11 12 13 14 15
15 PIN PLUG #2144 SPLIT PIN #2100
JOY UP
JOY DOWN
JOY RIGHT
JOY LEFT
BUTTON
COIN 1
GND GND GND
DBV
SPEAKER +
SPEAKER -
+12 VDC
white/black white/brown white/orange white/red white/yellow black/brown black black black/white yellow red/gray brown/gray orange
.250 FLAG
#648
.250 FLAG
#648
.250 FLAG
#648
.250 FLAG
#648
.250 FLAG
#648
.250 #653T
.250 #653T
.250 FLAG
#648
.250 FLAG
#648
.250 FLAG
#648
.250 FLAG
#648
.250 FLAG
#648
#639
.250
#653T
.250
#650
.110
#650
.110
9-PIN MINI CAP #2568 MALE MINI PIN 8 #2569 20-16 AWG MALE MINI #8162
1 2 3 4 5 6 7 8 9
#651
.187
#650
.110
#650
.110
#650
.110
BLACK WHITE
#PC20217
WHITE
BLACK
yellow
black/white
AC N AC L DBV GND
AC L
AC N
Speaker
UP
BUTTON
RIGHT
LEFT
DOWN
To Joystick
Joystick Ground
COIN
COIN
GREEN/YELLOW
Coin Lamps
#2874 - 3 con SJO
P9
58-1/2 "
57-1/2 "
58 " 61 " 46 "
57-1/2 "
4 " 4 " 4 " 5 "
17-1/2 "
28 "
19 "
56 "
51 "
26-1/2 "
59-1/2 "
73 "
35 "
#653T
.250
yellow
46 "
45-1/2 "
33 "
16 "
#2513
1 2
2 PIN PLUG #2103 SOLID PIN #2100S
#PC20217
GREEN/YELLOW
13 "
To Transformer
#2513
2 " STRIP2 " STRIP
