Ice I18B Operator's & Parts Manual

PARTS LIST
ICE i18B/i18C
18
*
ONLY FOR i18B
SOLUTION TANK ASSEMBLY
DIA PART
DESCRIPTION
NO
NO NUMBER REQ'D
1 8013001 SOLUTION TANK 1
2 8013010* 12V BATTERY 2
3 1321110 AUTO TAPPING SCREW ST3.5×10 1
4 8210531 KNOB, M6 1
5 1221640 PH SCREW M6×40, SS 1
6 1421409 PLAIN WASHER 4×9×0.8 1
7 8133002 PLUG 1
8 8013003 TRANSPARENT HOSE 1
9 8034012 BRACKET, CASTER 1
10 8013016 2" CASTOR 1
11 1421618 PLAIN WASHER 6×18×1.6 3
12 1422616 SPRING WASHER 6 SS 3
13 1021616 HEX HEAD SCREW M6×16,SS 3
14 1021830 HEX HEAD SCREW M8×30,SS 1
15 1422821 SPRING WASHER 8 3
16 1421824 PLAIN WASHER 8×24×2.0 1
17 8016010 WHEEL SHAFT 1
18 1421816 PLAIN WASHER 8×16×1.6 2
19 1021820 HEX HEAD SCREW M8×20,SS 4
20
8115200 8" WHEEL 2
1612607 BALL BEARING, 6004LU 4
21 1421828 PLAIN WASHER 8×28×3 2
22 8115203 WHEEL CAP 2
23 1962025 HOSE CLAMP 1
24 8013009 DECAL,RIGHT 1
25 8013002 BACKET 1
26 1221510 PH SCREW M5×10,SS 4
27 1421510 PLAIN WASHER 5×10×1,SS 4
28 8113009 WIRE CLAMP 4
29 8114751* WIRING BOOT 4
30 8013008 DECAL,LEFT 1
