PARTS LIST
ICE i18B/i18C
20
DIA PART
DESCRIPTION
NO
NO NUMBER REQ'D
9 8014034 BRCKET 1
10 1411824 PLAIN WASHER 8×24×2 6
11 1021820 HEX HEAD BOLT M8×20 6
12 8114030 FIXING BRACKET,CONTROL BOX 1
13 8014066 BATTERY CHARGER 24V 1
14 8113104 HANDLE 1
15 6210111 HOSE CLAMP 1
16 1221416 PH SCREW M4×16 SS 2
17 8014010 SQUEEGEE LIFTING HANDLE 1
18 8014008 CONTROL BOX 1
19 8034010 SQUEEGEE LIFTING ROPE 1
20 8114511 JOINT BEARING SQ6 1
21 1421618 PLAIN WASHER 6×18×1.6,SS 4
22 1121605 HEX NUT M6 2
23 1421828 PLAIN WASHER 8×28×3 2
24 1021830 HEX HEAD BOLT M8×30 2
25 1221512 PH SCREW M5×12,SS 1
26 8114005 PIPE COUPLING 1
27 8112030 CHARGER CORD (FOR US) 1
28 8014038 GASKET 1
29 8014036 PANEL 1
30 8014044 PLATE 1
31 1221516 PH SCREW M5×16 SS 2
32 1123608 SELFLOCKING NUT M6,SS 1
33 8114703 OVERLOAD PROTECTOR 35A 1
34 1421518 PLAIN WASHER 5×18×2 1
35 1021512 HEX HEAD BOLT M5×12,SS 1
36 8034011 BAFFLE 1
37 8014101 LIFTING ROPE SPACER 1
38 1021630 HEX HEAD BOLT M5×12,SS 1
39 8014045 TRANSPARENT PLATE 1
40 8014006 WATERPROOF SWITCH 250V 16A 2
41 8014043 WIRE BUFFER 1
42 8014041 WIRE CLAMP 1
43 1221616 PH SCREW M6×16,SS 1
44 2320403 STRAIN RELIEF 1
45 8014063 BATTERY CAPACITY INDICATOR 1
46 1221410 PH SCREW M4×10,SS 15
47 8014067 PANEL DECAL 1
48 8014069 FRONT PANEL 1
49 8114101 SHAFT 1
50 8014004 GASKET 1
51 1221412 PH SCREW M4×12, SS 4
52 1432411 SPRING WASHER 4 2
53 1411409 PLAIN WASHER 4×9×0.8 2
54 8014022 CONTROL TRIGGER 1
55 8014033 PLATE 1
56 1534608 SET SCREW M6×8 4
57 8014031 HEX BUSHING 1
58 8014032 SPRING ROD 1
59 8014035 SPRING 1
60 1211320 PH SCREW M3×20 2
61 1434300 WASHER WITH TOOTH 3 2
62 8114712 MICROSWITCH 1
63 1113507 SELFLOCKING NUT M5 7
64 8210421 RELAY 24VDC 30A 1
65 1123406 SELFLOCKING NUT M4, SS 2
