PARTS LIST
ICE i18B/i18C
22
DIA PART
DESCRIPTION
NO
NO NUMBER REQ'D
9 6210111 HOSE CLAMP 1
10 1221416 PH SCREW M4×16 SS 2
11 8014010 SQUEEGEE LIFTING HANDLE 1
12 8014008 CONTROL BOX 1
13 8034010 SQUEEGEE LIFTING ROPE 1
14 8114511 JOINT BEARING SQ6 1
15 1421618 PLAIN WASHER 6×18×1.6,SS 4
16 1121605 HEX NUT M6 2
17 1421828 PLAIN WASHER 8×28×3 2
18 1021830 HEX HEAD BOLT M8×30 2
19 1221512 PH SCREW M5×12 1
20 1221516 PH SCREW M5×16 SS 2
21 8014044 PLATE 1
22 8114005 PIPE COUPLING 1
23 8014037 PANEL, BOTTOM 1
24 8014038 GASKET 1
25 8014068 OVERLOAD PROTECTOR 10A 1
26 8014053 POWER CORD 1
27 1221410 PH SCREW M4×10,SS 17
28 1123608 SELFLOCKING NUT M6,SS 1
29 8034011 BAFFLE 1
30 1421512 PLAIN WASHRE 5×12×1.5 6
31 1021512 HEX HEAD BOLT M5×12,SS 1
32 8014101 LIFTING ROPE SPACER 1
33 1021630 HEX HEAD BOLT M6×30,SS 1
34 8014006 WATERPROOF SWITCH 250V 16A 2
35 8014041 WIRE CLAMP 1
36 8014043 WIRE BUFFER 1
37 1221614 PH SCREW M6×14 1
38 1422616 SPRING WASHER 6 1
39
2320403 STRAIN RELIEF 1
40 8014007 PANEL DECAL 1
41 8014005 FRONT PANEL 1
42 8014004 GASKET 1
43 8114101 SHAFT 1
44 1221412 PH SCREW M4×12,SS 2
45 1411409 PLAIN WASHRE 4×9×0.8 2
46 1432411 SPRING WASHER 4 2
47 8014033 PLATE 1
48
8014022 CONTROL TRIGGER 1
49 1534608 SET SCREW M6×8 4
50 8014031 HEX BUSHING 1
51 8014032 SPRING ROD 1
52 8014035 SPRING 1
53 1211325 PH SCREW M3×25 2
54 1411309 PLAIN WASHER 3×9×0.8 4
55 8014071 SWITCH 1
56 8014061 SWITCH BRACKET 1
57 8014002 REAR PANEL 1
58 8014034 BRACKET 1
