Ice I18B Operator's & Parts Manual

ICE i18B/i18C
30
PARTS LIST
DIA
NO.
PART
NUMBER
DESCRIPTION
NO
REQ'D
1 1123810 LOCK NUT M8 2
2 1421824 FLAT WASHER M8×
∮
24×2.0 4
3 8116009 PROTECTIVE WHEEL 2
4 1021616 HEX BOLT M6×16 2
5 8115404 BEARING, JOURNAL 2
6 1421612 FLAT WASHER M6×
∮
12×1.6 2
7 8118300 RIGHT BRACKET 1
8 8118400 CASTER, 2 INCH 2
9 8118600 CLAMP ASSEMBLY, SQUEEGEE 1
10
8118022 SQUEEGEE BLADE, REAR, LINATEX 1
8118002 SQUEEGEE BLADE, REAR, PU (OPTION) 1
11 8118003 STAR KNOB M8 4
12 8118004 SQUEEGEE HOUSING 1
13 1021835 HEX BOLT M8×35 2
14 8118009 RETAINER,SQUEEGEE 1
15 8118008 SPACER 1
16 1222515 SCREW M5×15 6
17 8118010 RETAINER ASSEMBLY 1
18
8118021 SQUEEGEE BLADE, FRONT, LINATEX 1
8118001 SQUEEGEE BLADE, FRONT, PU (OPTION) 1
19 8118610 SHORT CLAMP ASSEBLY 1
20 1221575 SCREW M5×75 1
21 8118200 LEFT BRACKET 1
22 1121008 HEX NUT M10 2
23 8118600A CLAMP ASSEMBLY 1
24 8118624 SHAFT 1
25 8118623 SPACER 1
26 1123507 LOCK NUT M5 1
27 8011003 VACUUM HOSE 1
28
8118000 SQUEEGEE ASSEMBLY, LINATEX 1
8118000-PU SQUEEGEE ASSEMBLY, PU 1
SQUEEGEE ASSEMBLY
