Ice I18B User Manual

6'8:92/9:
ICE I18B/I18C

15
*
ONLY FOR I18B
8+)5<+8?:'41'99+3(2?
DIA PART
DESCRIPTION
NO
NO NUMBER REQ'D
1 8011001 RECOVERY TANK 1
2 1221410 PH SCREW M4×10,SS 3
3 8011011 DECAL,LEFT 1
4 4010316 ICE LOGO 3
5 8011030 DRAIN HOSE 1
6 8012007 CONNECTING PLATE 1
7 8012008 BUSHING 1
8 1421618 PLAIN WASHER 6×18×1.6 3
9 1221616 PH SCREW M6×16, SS 1
10 1962050 HOSE CLAMP 27-51mm 2
11
8112002* VACUUM MOTOR 24V, 500W 1
8011023 VACUUM MOTOR 110V, 500W 1
12 8011003 VACUUM HOSE 1
13 1113608 SELFLOCKING NUT M6 3
14 1411612 PLAIN WASHER 6×12×1.6 3
15 8011007 MUFFLER 1
16 8112005 GASKET 1
17 8112006 BOLT 3
18 1111605 HEX NUT M6 3
19 8011012 DECAL,RIGHT 1
20 8011009 PLATE 2
21 1421409 PLAIN WASHER 4×9×0.8,SS 5
22 8111015 FLOAT CAGE 1
23 8111014 FLITER COUPLING 1
24 1021616 HEX HEAD BOLT M6×16 2
25 8111001 GASKET 1
26 8113007 RUBBER STRIP 1
27 1321110 AUTO TAPPING SCREW ST3.5×10 1
28 8131003 CAP 1
29 1123406 SELFLOCKING NUT M4, SS 1
30
8112008* CARBON BRUSH 2
8011022 CARBON BRUSH 2
