Ice I18B User Manual

6'8:92/9:
ICE I18B/I18C

18
*
ONLY FOR I18B
952;:/54:'41'99+3(2?
DIA PART
DESCRIPTION
NO
NO NUMBER REQ'D
1 8013001 SOLUTION TANK 1
2 8013010* 12V BATTERY 2
3 1321110 AUTO TAPPING SCREW ST3.5×10 1
4 8210531 KNOB, M6 1
5 1221640 PH SCREW M6×40, SS 1
6 1421409 PLAIN WASHER 4×9×0.8 1
7 8133002 PLUG 1
8 8013003 TRANSPARENT HOSE 1
9 8013017 DECAL 1
10 8013019 BOLT WITH SHOULDER 4
11 8013011 SLIDER HOUSING 1
12 8013021 PLUNGER 1
13 1123608 SELF-LOCKING NUT M6 SS 4
14 1421618 PLAIN WASHER 6×18×1.6 6
15 1647320 PING 3×20 1
16 8013013 SLIDER 1
17 1411030 PLAIN WASHER 10×30×2.5 1
18 8013016  1
19 1421020 PLAIN WASHER 10×20×2 1
20 1422026 SPRING WASHER 10 SS 1
21 1031032 HEX HEAD SCREW M10×32 1
22 8016010 WHEEL SHAFT 1
23 1411816 PLAIN WASHER 8×16×1.6 2
24 1432821 SPRING WASHER 8 2
25 1021820 HEX HEAD SCREW M8×20,SS 4
26 8115200  2
27 1421828 PLAIN WASHER 8×28×3 2
28 8115203 WHEEL CAP 2
29 1962025 HOSE CLAMP 1
30 8013004 DECAL,BALL VALVE 1
31 8013009 DECAL,RIGHT 1
32 1021616 HEX HEAD SCREW M6×16,SS 2
33 1422616 SPRING WASHER 6 SS 2
34 8013002 BACKET 1
35 1221510 PH SCREW M5×10,SS 4
36 1421510 PLAIN WASHER 5×10×1,SS 4
37 8113009 WIRE CLAMP 4
38 8114751* WIRING BOOT 4
39 8013008 DECAL,LEFT 1
