ICE I18B/I18C

27
97;++-++.52*+8'99+3(2?
DIA PART
DESCRIPTION
NO
NO NUMBER REQ'D
1 8017003 SPRING 1
2 1411816 PLAIN WASHER 8×16×1.6 3
3 1432821 SPRING WASHER 8 3
4 1021820 HEX HEAD BOLT M8×20,SS 3
5 1021230 HEX HEAD BOLT M12×30,SS 2
6 8015117 NYLON WASHER 12.5×32×1.5 4
7 8115001 SQUEEGEE SUPPORT 1
8 1123115 SELFLOCKING NUTS M12 2
9 8017010 SQUEEGEE BRACKET 1
10 8117006 CUSHION 2
11 8115005 SPACER 16×12×6.5 2
12 8017002 SPRING 1
13 1644248 PIN 12×48 1
14 1645324 COTTER PIN 3
15 8017024 SUPPORTING PIPE 1
16 8017020 SQUEEGEE HOLDER 1
17 1221550 PH SCREW M5×50 1
18 8017005 BUSHING 1
19 1123507 SELF-LOCKING NUT M5 1
