Ice I18B User Manual

ICE I18B/I18C

30
6'8:92/9:
97;++-++'99+3(2?
DIA PART
DESCRIPTION
NO
NO NUMBER REQ'D
1 8116009 BUMPING WHEEL 2
2 8115404 SPACER 2
3 1021616 HEX HEAD BOLT M6×16,SS 2
4 1421618 PLAIN WASHER 6×18×1.6,SS 2
5 1111008 HEX NUT M10 2
6 8118400  2
7 8118004 SQUEEGEE BRACKET 1
8 8118003 HANDLE 4
9 8118300 BRACKET,RIGHT 1
10 1021835 HEX HEAD BOLT M8×35,SS 2
11 1121807 HEX NUT M8,SS 4
12 1021860 HEX HEAD BOLT M8×60 4
13 8118600 CLAMP ASSEMBLY 1
14 1123507 SELFLOCKING NUT M5 1
15 1221570 PH SCREW M5×70 1
16 8118610 CLAMP ASSEMBLY 1
17
8118022 REAR SQUEEGEE 1
8118002 REAR SQUEEGEE, PU (OPTIONAL) 1
8118012 REAR SQUEEGEE, CR (OPTIONAL) 1
18
8118021 FRONT SQUEEGEE, LINATEX 1
8118001 FRONT SQUEEGEE, PU (OPTIONAL) 1
8118011 FRONT SQUEEGEE, CR (OPTIONAL) 1
19 8118005 SQUEEGEE HOLDER 1
20 8118200 BRACKET,LEFT 1
21 1421816 PLAIN WASHER 8×16×1.6,SS 4
22 1123810 SELFLOCKING NUT M8 2
