Ice i20NB User Manual

20
ICE i20NB / i20NBT / i20NBT-OB / i24BT
PARTS LIST
SOLUTION TANK GROUP
DIA
NO.
PART
NUMBER
DESCRIPTION
NO
REQ'D
33 8113012 BATTERY TRAY 1
34 8114750 BATTERY CONNECT CABLE, BLACK 1
35 8114751 JACKET, BATTERY TERMINAL, BLACK 4
36 1421510 FLAT WASHER M5×
∮
10×1 17
37 8119100 FILTER ASSEMBLY 1
38 8133025 LABEL, LEFT SIDE 1
39 1321110 SELF-TAPPING SCREW ST3.5 ×10 4
40 1421409 FLAT WASHER M4×
∮
9×0.8 5
41 8133610 LED LIGHT, KIT 1
42 8133601 LED LIGHT MNTG BASE 1
43 1221520 SCREW M5X20 3
44 8133602 LED LIGHT COVER 1
45 8113030 SEAL 1
46 8113002 COVER 1
47 8113007 STRAP 1
48 1321213 SELF-TAPPING SCREW ST4.2X13 1
49 4010316 ICE Logo 2
50 8133026 LABEL, RIGHT SIDE 1
51 1123305 LOCK NUT M3 2
52 8113010 BRACKET, CONNECTOR MTG 1
53 1434300 LOCK WASHER, TOOTH, M3 2
54 1211325 SCREW M3×25 2
55 8134783 BATTERY CONNECT CABLE, ASSEMBLY 1
56 1422513 LOCK WASHER M5 2
57 8133002 CAP, SOLUTION FILL 1
58 8113009 NYLON, CLAMP 9
