Ice i20NB User Manual

23
ICE i20NB / i20NBT / i20NBT-OB / i24BT
PARTS LIST
CONTROL CONSOLE GROUP（i20NB）
DIA
NO.
PART
NUMBER
DESCRIPTION
NO
REQ'D
36 8134082 CABLE, SQGE LIFT 1
37 8014101 LIFTING ROPE SPACER 1
38 1021512 HEX HEAD BOLT M5×12,SS 1
39 1421515 FLAT WASHER M5×
∮
15×1.0 1
40 1123608 LOCK NUT M6 3
41 8014012 BAFFLE 1
42 8113111 NYLON FLAT WASHER
∮
12.9×
∮
25.4×0.8 1
43 1121605 HEX NUT M6 2
44 8134501 BRACKET 1
45 8134081 SLEEVEE 1
46 1421132 FLAT WASHER M12×
∮
32×1.5 1
47 8134080 SQUEEGEE LIFTING HANDLE 1
48 8113104 BALL KNOB M8 1
49 1222641 SUNK HEAD SCREW M6 X 40 2
50 8210112 HOOK, POWER CORD 2
51 8014054 STRAIN RELIEF 1
52 6210111 CLAMP, DRAIN HOSE 1
53 1023612 HEX BOLT M6 X 12, COPPER 6
54 1422616 LOCK WASHER, M6 11
55 1423612 FLAT WASHER M6×
∮
12×1, COPPER 6
56 8134790 MAIN CONTROLLER, i20NB 1
57 8134070 REAR PLATE, CONTROL CONSOLE 1
58 1421824 FLAT WASHER M8×
∮
24×2 10
59 1021820 HEX BOLT M8×20 10
60 1221620 PH SCREW M6 X 20 2
61 8114712 MICRO SWITCH 1
62 1021320 SCREW M3 X 20 2
63 8134022 BRACKET,SWITCH 1
64 8114402 BRACKET, SPRING 1
65 1521616 SCREW M6X16, HEX SCOKET 2
66 1534608 SET SCREW M6 ×8 4
67 8134300 LEVER, BAIL 1
68 8114300 ACTUATOR 1
69 8114306 SPRING 1
70 1535630 SET SCREW M6 ×30 1
71 8114101 SHAFT 1
