Ice i20NB User Manual

25
ICE i20NB / i20NBT / i20NBT-OB / i24BT
PARTS LIST
CONTROL CONSOLE GROUP（i20NBT /i24BT）
DIA
NO.
PART
NUMBER
DESCRIPTION
NO
REQ'D
1
8114709 KEY SWITCH 1
8114752 KEY 1
2 1221512 SCREW M5×12 17
3 1422513 LOCK WASHER M5 6
4 1421510 FLAT WASHER M5×
∮
10×1.0 13
5
8144724 CONTROL PANEL DECAL, i20NBT 1
8144725 CONTROL PANEL DECAL, i24BT 1
6 8144720 CONTROL PANEL, i20NBT 1
7 8134015 GASKET 1
8
8144795 CONTROL PANEL PCB, i20NBT (AGM / EN) 1
8144797 CONTROL PANEL PCB, i20NBT (WET FLOODED / EN) 1
9 1221306 SCREW M3×6 7
10 8134005A CONTROL HOUSING, i20NB 1
11 1021616 HEX BOLT M6 X 16 5
12 1421618 PLAIN WASHER M6×
∮
18×1.6,SS 10
13 8114008 BRACKET, SQGE STORAGE 1
14 8310740 CIRCUIT BREAKER, 5A 1
15 1221421 SCREW M4×20 2
16 1421409 FLAT WASHER M4×
∮
9×0.8 2
17 8124715A EMERGENCY STOP SWITCH, KIT 1
18 8144030 BASE, CIRCUIT BREAKERS MNTG 1
19 8124008 SPRING 2
20 8124716 LED LIGHT 1
21 8124007 BUTTON,EMERGENCY STOP 1
22 8124710 EMERGENCY STOP SWITCH KIT 1
23 8144025 LABEL, CIRCUIT BREAKER 1
24 1221515 PH SCREW M5×15 4
25 1123507 LOCK NUT M5 6
26 1123305 LOCK NUT M3 6
27 8113010 BRACKET, CONNECTOR MTG 1
28 8134750 CONNECTOR, GRID, BLUE 1
29 1434300 LOCK WASHER, TOOTH, M3 6
30 1211325 SCREW M3×25 2
31 8134060 PLATE, ON BOARD BATTERY CHARGER 1
32 8134061 CLEAR COVER 1
33 1221412 SCREW M4×12 4
34
8132010-US
ON BOARD BATTERY CHARGER,KIT 1
35 8112030A BATTERY CHARGER POWER CORD, KIT 1
36 8132010A ON BOARD BATTERY CHARGER 1
37
1123406 LOCK NUT M4 4
38
8114005 CONNECTOR 1
39
1021840 HEX BOLT M8×40 2
