24
ICE i20NB / i20NBT / i20NBT-OB / i24BT
PARTS LIST
CONTROL CONSOLE GROUP (i20NB)
DIA
NO.
PART
NUMBER
SERIAL NUMBER DESCRIPTION
NO
REQ'D
1 8134001
000101-
CONTROL CONSOLE HOUSING 1
2 1221306
000101-
PAN HEAD SCREW M3×6 5
3 1421307
000101-
FLAT WASHER M3×
∮
7×0.5 5
4 8114701
000165-000270
PCB ASSEMBLY 1
5 8134015
000101-
GASLET 1
6 1123305
000101-
LOCK NUT M3 4
7 8114710
000101-
TIMER 1
8 8114709
000101-
KEY SWITCH 1
9 8134010
000101-
CONTROL PANEL 1
10 8134014
000101-
CONTROL PANEL DECAL, I20NB 1
11 1221512
000101-
PAD SCREW M5×12 12
12 1021616
000101-
HEX HEAD BOLT M6 X 16 7
13 1421618
000101-
PLAIN WASHER M6×
∮
18×1.6, SS 15
14 8114008
000101-
BRACKET, SQGE STORAGE 1
15 8114703
000101-
CIRCUIT BREAKER, 35A 2
16
8134006
000101-
PLATE, CIRCUIT BREAKERS MNTG 1
17 8144021
000101-
LABEL, CIRCUIT BREAKER 1
18 8114005
000101-
CONNECTOR 1
19 1421510
000101-
FLAT WASHER M5×
∮
10×1.0 3
20 1021630
000101-
HEX HEAD BOLT M6×30,SS 1
21 8014101
000101-
LIFTING ROPE SPACER 1
22 1021512
000101-
HEX HEAD BOLT M5×12,SS 2
23 1421515
000101-
FLAT WASHER M5×
∮
15×1.0 1
24 8134013
000165-000527
CABLE, SQGE LIFT 1
25 1021620
000101-
HEX HEAD BOLT M6×20,SS 2
26 8014012
000101-
BAFFLE 1
27 1123608
000101-
LOCK NUT M6 10
28 8134501
000101-
BRACKET 1
29 8134508
000101-
SLEEVE 1
30 1421132
000101-
FLAT WASHER M12×
∮
32×1.5 2
31 8014010
000101-
SQUEEGEE LIFTING HANDLE 1
32 8113104
000101-
BALL KNOB M8 1
33 1121605
000101-
HEX NUT M6 2
34 1021840
000101-
HEX HEAD BOLT M8×40 2
