Ice i20NBT-OB User Manual

25
ICE i20NB / i20NBT / i20NBT-OB / i24BT
PARTS LIST
DIA
NO.
PART
NUMBER
SERIAL NUMBER DESCRIPTION
NO
REQ'D
35 1422821
000101-
LOCK WASHER M8 8
36 1421828
000101-
FLAT WASHER M8×
∮
28×3 2
37 6210111
000101-
CLAMP, DRAIN HOSE 1
38 1221515
000101-
PAN HEAD SCREW M5×15 2
39 8114712
000101-
MICRO SWITCH 1
40 1434300
000101-
LOCK WASHER, TOOTH, M3 2
41 1021320
000101-
HEX HEAD SCREW M3×20 2
42 8134022
000101-
BRACKET,SWITCH 1
43 8114402
000101-
BRACKET, SPRING 1
44 1521616
000101-
SCREW M6X16, HEX SCOKET 2
45 8114300
000101-
ACTUATOR 1
46 1534608
000101-
SET SCREW M6 ×8 4
47 1535630
000101-
SET SCREW M6 ×30 1
48 8114306
000101-
SPRING 1
49 8114101
000101-
SHAFT 1
50 8134300
000101-
LEVER, BAIL 1
51 1021610
000101-
HEX HEAD BOLT M6 X 10 4
52 1422616
000101-
LOCK WASHER, M6 4
53 8114705
000101-
STAND-OFF, M6 2
54 8134021
000101-
REAR PLATE, CONTROL CONSOLE 1
55 1421824
000101-
FLAT WASHER M8×
∮
24×2 6
56 1021820
000101-
HEX HEAD BOLT M8×20 6
57 8124704
000165-000270
SOLENOID SWITCH 1
58 1123507
000101-
LOCK NUT M5 1
59 8114707
000165-000270
RELAY, 40A 1

Ice i20NBT-OB Specifications

General

Brand	Ice
Model	i20NBT-OB
Category	Scrubber
Language	English
