33
ICE i20NB / i20NBT / i20NBT-OB / i24BT
PARTS LIST
CONTROL CONSOLE GROUP (i20NBT/i24BT)
DIA
NO.
PART
NUMBER
SERIAL NUMBER DESCRIPTION
NO
REQ'D
1 8134001
000101-
CONTROL CONSOLE HOUSING 1
2 1421307
000101-
FLAT WASHER M3×
∮
7×0.5 5
3 1221306
000101-
SCREW M3×6 5
4 8124701
000187-000603 for i20NBT
PCB ASSEMBLY 1
000139-000321 for i24BT
5 8134015
000101-
GASLET 1
6 1123305
000101-
LOCK NUT M3 6
7 8114710
000101-
TIMER 1
8
8114709
000101-
KEY SWITCH 1
8114752
000101-
KEY 1
9 8124717A 000101- POTENTIOMETER, KIT 1
10 8124718 000101- KNOB, POTENTIOMETER 1
11 8144010
000101-
CONTROL PANEL 1
12
8144014
000101-
CONTROL PANEL DECAL, i20NBT 1
8144015
000101-
CONTROL PANEL DECAL, i24BT 1
13 1221512
000101-
SCREW M5×12 12
14 1021616
000101-
HEX BOLT M6 X 16 7
15 1421618
000101-
PLAIN WASHER M6×
∮
18×1.6,SS 15
16 8114008 000101- BRACKET, SQGE STORAGE 1
17 8124007
000101-
BUTTON,EMERGENCY STOP 1
18 8144022
000101-
LABEL, CIRCUIT BREAKER 1
19 8124008
000101-
SPRING 2
20 8144030
000101-
BASE, CIRCUIT BREAKERS MNTG 1
21 8114703
000101-
CIRCUIT BREAKER, 35A 3
22 8124715A
000101-
EMERGENCY STOP SWITCH, KIT 1
23 1421409 000101- FLAT WASHER M4×
∮
9×0.8 2
24 1221421 000101- SCREW M4×20 2
25 8114005
000101-
CONNECTOR 1
26 1421510
000101-
FLAT WASHER M5×
∮
10×1.0 5
27 1021630
000101-
HEX HEAD BOLT M6×30,SS 1
28 8014101
000101-
LIFTING ROPE SPACER 1
29 1021512
000101-
HEX HEAD BOLT M5×12,SS 2
30 1421515
000101-
FLAT WASHER M5×
∮
15×1.0 1
31 8134013
000187-000603 for i20NBT
CABLE, SQGE LIFT 1
000139-000321 for i24BT
32 1021620
000101-
HEX HEAD BOLT M6×20,SS 2
To Next Page
