34
ICE i20NB / i20NBT / i20NBT-OB / i24BT
PARTS LIST
CONTROL CONSOLE GROUP (i20NBT/i24BT)
DIA
NO.
PART
NUMBER
SERIAL NUMBER DESCRIPTION
NO
REQ'D
33 8014012
000101-
BAFFLE 1
34 1123608 000101- LOCK NUT M6 10
35 8134501
000101-
BRACKET 1
36 8134508
000101-
SLEEVE 1
37 1421132 000101- FLAT WASHER M12×
∮
32×1.5 2
38 8014010
000101-
SQUEEGEE LIFTING HANDLE 1
39 8113104
000101-
BALL KNOB M8 1
40 1121605 000101- HEX NUT M6 2
41 1021840
000101-
HEX HEAD BOLT M8×40 2
42 1422821
000101-
LOCK WASHER M8 8
43 1421828 000101- FLAT WASHER M8×
∮
28×3 2
44 6210111
000101-
CLAMP, DRAIN HOSE 1
45 1221515
000101-
PAN HEAD SCREW M5×15 2
46 1123507
000101-
LOCK NUT M5 3
47 8124501
000187-000603 for i20NBT
SPEED CONTROL BOARD 1
000139-000321 for i24BT
48 8124743
000101-
MICRO SWITCH 1
49 8114712 000101- MICRO SWITCH 1
50 1434300
000101-
LOCK WASHER, TOOTH, M3 4
51 1021320
000101-
HEX HEAD SCREW M3×20 4
52 8134022 000101- BRACKET,SWITCH 1
53 8114402
000101-
BRACKET, SPRING 1
54 1521616
000101-
SCREW M6X16, HEX SCOKET 2
55 8114300 000101- ACTUATOR 1
56 1534608
000101-
SET SCREW M6 ×8 4
57 1535630
000101-
SET SCREW M6 ×30 1
58 8114306 000101- SPRING 1
59 8114101
000101-
SHAFT 1
60 8134300
000101-
LEVER, BAIL 1
61 1021610 000101- HEX HEAD BOLT M6 × 10 4
62 1422616
000101-
LOCK WASHER, M6 4
63 8114705
000101-
STAND-OFF, M6 2
64 8134021
000101-
REAR PLATE, CONTROL CONSOLE 1
65 1421824
000101-
FLAT WASHER M8×
∮
24×2 6
66 1021820
000101-
HEX HEAD BOLT M8×20 6
To Next Page
