ICE i20NB / i20NBT / i20NBT-OB / i24BT
PARTS LIST
RECOVERY TANK GROUP
DIA
NO.
PART
NUMBER
SERIAL NUMBER DESCRIPTION
NO
REQ'D
1 8111022 000101- WARNING LABEL 1
2 8131002 000101- RECOVERY TANK COVER 1
3
8111005
000165-001099 for i20NB
RECOVERY TANK COVER SEAL 1
000187-000776 for i20NBT
000139-000482 for i24BT
8131005-2
001010- for i20NB
000777- for i20NBT
000483- for i24BT
4 1021616 000101- HEX BOLT M6 X 16 12
5 1421618 000101- FLAT WASHER M6×
∮
18×1.6 10
6 8111014 000101- FLOAT ADAPTER 1
7 8111001 000101- GASKET 1
8 8111015 000101- FLOAT, SHUT-OFF 1
9 8131003 000101- CAP 1
10 8131001 000101- RECOVERY TANK 1
11 8131010 000101- DRAIN HOSE 1
12 1962050 000101- CLAMP 1
13 8111300 000101- HINGE ASSEMBLY 2
14 8131020 000101- CABLE 1
15 1421612 000101- FLAT WASHER M6×
∮
12×1.6 2
16 8111024 000101- LABEL, BATTERY INSTALLATION 1
17 4010316 000101- ICE LOGO 1
18 8111008 000101- BRACKET 1
19 1421816 000101- FLAT WASHER M8×
∮
16×1.6 2
20 8111007 000101- RECOVERY TANK SUPPORT 1
21 8115404 000101- SLEEVE, P/M 1
22 1021830 000101- HEX BOLT M8×30 1
23 8111016 000101- PLATE 2
24 1221412 000101- SCREW M4×12 2
