Ice i20NBT User Manual

17
ICE i20NB / i20NBT / i20NBT-OB / i24BT
PARTS LIST
VACUUM FAN GROUP
DIA
NO.
PART
NUMBER
SERIAL NUMBER DESCRIPTION
NO
REQ'D
1 8112005
000101-
GASKET, VACUUM MOTOR 1
2 1121605
000101-
HEX NUT M6 3
3 8112006 000101- STUD M6×92 3
4
8116500
000165-000511 for i20NB
AMETEK VACUUM MOTOR , KIT, 24VDC
1
000187-000448 for i20NBT
000139-000281 for i24BT
8132005
000512- for i20NB
CARBON BRUSH, 24VDC VACUUM MOTOR
1
000449 - for i20NBT
000282- for i24BT
5 1421612
000101-
FLAT WASHER M6×
∮
12×1.6 7
6 1123608
000101-
LOCK NUT M6 3
7 8112003 000101- BRACKET 1
8 1021616
000101-
HEX HEAD BOLT M6×16 4
9 8132007
000101-
MUFFLER, VACUUM MOTOR 1
10 1914300 000101- TIE, NYLON, 5X300 2
11 8112030
000101-
POWER CORD, BATTERY CHARGER, US 1
12 8132010A
000101-
ON BOARD BATTERY CHARGER, 13A 1
13 8132020-US
000165-000527 for i20NB
ON BOARD BATTERY CHARGER, KIT, US
1
000187-000603 for i20NBT
000139-000321 for i24BT
14 8112001 000101- CHARGER COVER 1
15 8118003
000101-
KNOB M8 1
16 1421515
000101-
FLAT WASHER M5×
∮
16×1.0 4
17 1221516 000101- PAN HEAD SCREW M5X16 4
18 8131008
000101-
CLAMP, ON BOARD BATTERY CHARGER 2
19 1421510
000101-
FLAT WASHER M5×
∮
10×1.0 4
20 1123507 000101- LOCK NUT M5 4
21 8112004
000101-
BRACKET 1
