65
ICE i20NB / i20NBT / i20NBT-OB / i24BT
PARTS LIST
SCRUB HEAD LIFT GROUP (i24BT)
DIA
NO.
PART
NUMBER
SERIAL NUMBER DESCRIPTION
NO
REQ'D
1 8137006 000101- NON-SLIP MAT 1
2 8137100 000101- BRACKET, SCRUB HEAD LIFT 1
3 8133151 000287- BUMPER 1
4 1123810 000101- LOCK NUT M8 5
5 1021830 000101- HEX BOLT M8×30 2
6 1421824 000101- FLAT WASHER M8×
24×2 8
7 8117007 000101- NYLON WASHER
12.9×
24×2.5 4
8 8115404 000101- BEARING, JOURNAL 4
9 8115405 000101- SLEEVE, P/M 2
10 1123115 000101- LOCK NUT M12 1
11 1421124 000101- FLAT WASHER M12
×
24
×
2.5 1
12 8126011 000101- LEFT BRACKET 1
13 1422821 000101- LOCK WASHER M8 3
14 1021820 000101- HEX BOLT M8×20 3
15 1022845 000101- HEX BOLT M8 ×45 1
16 8117004 000101- ROLLER 1
17 8126010 000101- RIGHT BRACKET 1
18 1021616 000101- HEX BOLT M6 ×16 2
19 1422616 000101- LOCK WASHER M6 2
20 1421612 000101- FLAT WASHER M6×
12×1.6 2
21 8137001 000101- BRACKET, GUIDE 1
