ICE i20NB / i20NBT / i20NBT-OB / i24BT

PARTS LIST

SOLUTION GROUP

DIA

NO.

PART

NUMBER

SERIAL NUMBER DESCRIPTION

REQ'D

1 8119007 000101- ELBOW G1/2 1

2 8119005 000101- BALL VALVE, G1/2 1

3 8119006 000101- CLAMP 5

4 8119201 000101- TUBING ID=12MM L=70MM 1

5 8119002 000101- ELBOW, TUBING BARB 2

6 8119202 000101- TUBING ID=12MM L=100MM 1

8119100 000101- FILTER ASSEMBLY, 70 MESH 1

8119200 000101- FILTER ASSEMBLY, 40 MESH 1

8 8119101 000101- BASE, FILTER ASSEMBLY 1

8119103 000101- SCREEN, FILTER, 70 MESH 1

8119105 000101- SCREEN, FILTER, 40 MESH (OPTION) 1

10 1622760 000101- O RING 1

11 8119102 000101- CAP, FILTER ASSEMBLY 1

12 1421510 000101- FLAT WASHER M5×

∮

10×1 2

13 1221512 000101- SCREW M5×12 2

14 8119202 000101- TUBING ID=12MM L=100MM 1

15 1221412 000101- SCREW M4×12 2

16 1422411 000101- LOCK WASHER M4 2

17 1421409 000101- FLAT WASHER M4×

∮

9×0.8 2

18 8119003 000101- SOLENOID VALVE,24VDC 1

19 1962016 000101- CLAMP, 10-16mm 5

20 8119203 000101- TUBING ID=12MM L=135MM 1

21 8119204 000101- TUBING ID=10MM L=360MM 1

22 8116100 000101- WATER SUPPLY TUBE 1
