Ice iE410 User Manual

12 ICE iE410
OPERATOR
DIA
NO
PART
NUMBER
DESCRIPTION
NO
REQ'D
1 6180208 Coupler, Quick Connect 1
2 1421432 Washer, Plain ,Ø13.5XØ32X1.5 1
3 1421428 Washer, Plain ,Ø14XØ32X1.5 1
4 6180115 Elbow, Strect, 45
°
1
5 6180128 Barb, Hose 2
6 1962016 Clamp, Hose 3/8" 6
7 6210116 Hose, High Pressure 1
8 6210607 Barb,Pump 1
9 6210604U Solution Solenoid, 120V/60HZ 1
10 6210606 Connector, Three-way 1
11 6210603 Connector 1
12 6210602 Barb, Pump 1
13 6210601 Mounting Frame, Pump 1
14 6150195 Pump,115V,100PSI 1
15 2310116 Gasket, Vac Motor 1
16 2310135A Vac Motor,3-STAGE 120V (With terminal) 1
17 1421617 Washer, SST,Plain,Ø6XØ16X2 11
18 6180210 Bend, Nylon, Pump 1
19 6210117 Hose, Solution 1
20 2310122 Stud 3
21 1914300 Tie, Cable 1
22 2320208 Acoustic Insulation Pipe 1
23 1123608 Nut,Lock,SS,M6 3
24 1121605 Nut,SST,M6 4
25 6110011 Cap, Axle 2
26 1422616 Washer, Lock, Ø6 5
27 8111020 Cable 1
28 6210105 Spacer 2
29 1222515 Screw, FH, M5X15, SST 8
30 6160406 Hinger,SST 4" 2
31 1222520 Screw,FH,SST, M5X20 6
32 1221616 Screw,SST,PH,M6X16 2
33 1962050 Clamp, Hose 2" 1
34 1421515 Washer,SST,PLAIN,Ø5XØ15X1 10
35 1422513 Washer, Lock, Ø5 10
36 1121505 Nut,SST,M5 6
37 6210140 Carpet Pick-up Tool 1
38 6210407 Spring 1
39 6210400U Mounting Base Assy, Brush 1
PARTS LIST

Ice iE410 Specifications

General

Brand	Ice
Model	iE410
Category	Floor Machine
Language	English
