28 ICE RS26+ / RS32+
OPERATOR MANUAL
CONTROLLER GROUP
DIA
NO.
PART
NUMBER
DESCRIPTION
NO
REQ'D
1 1021616 SCREW, HEX HEAD, M6×16 12
2 1422616 LOCK WASHER, M6 20
3 1421618 FLAT WASHER, M6×
∮
18×1.6 14
4 8310480 FUSE, 150A 1
5 8114705 INSULATOR 3
6 8310422 BRACKET, INSULATOR 2
7 8310133 RUBBER GROMMET 4
8 8310740 CIRCUIT BREAKER, 5A 2
9 1021820 BOLT, HEX HEAD,M8×20 4
10 1422821 SPRING LOCK WASHER, M8 9
11 1421828 FLAT WASHER, M8×
∮
28×2.5 9
12 1123507 LOCK NUT, M5 4
13 1421510 FLAT WASHER, M5.3×
∮
10×1.0 8
14 8320454 BRCKET, CHARGER 1
15 8210106
ON BOARD BATTERY CHARGER, 25A
1
16 1221520 SCREW, PAN HEAD, M5×20 4
17
8112030 POWER CORD, BATTERY CHARGER, US 1
8112040 POWER CORD, BATTERY CHARGER, EU 1
8112050 POWER CORD, BATTERY CHARGER, JP 1
8112060 POWER CORD, BATTERY CHARGER, CH 1
8112070 POWER CORD, BATTERY CHARGER, UK 1
18 1211330 SCREW, PAN HEAD, M3×30 2
19 8310425 BRACKET 2
20 8320450 BRACKET, SCRUB HEAD LIFTING 1
21 1021825 BOLT, HEX HEAD, M8×25 5
22 1123305 LOCK NUT, M3 4
23 1434300 WASHER, TOOTH, M3 4
24 8310423 MICRO SWITCH 1
25 1421307 FLAT WASHER, M3×
∮
7×0.5 2
26 1211320 SCREW, PAN HEAD, M3×20 2
27 8113020 CONNECTOR 1
28 1423612 FLAT WASHER M6×
∮
12×1 10
29 1023612 HEX BOLT M6 × 12, COPPER 10
30 1421409 FLAT WASHER, M4×
∮
9×0.8 4
31 1422411 LOCK WASHER, M4 4
32 1221416 SCREW, HEX HEAD, M4×16 4
33 8313421 CONNECT PLATE 1
34 8313420 RELAY, 24VDC 120A 2
35 8313400 MAIN CONTROLLER 1
36 8320453 BRCKET, MAIN CONTROLLER 1
