Ice RS26+ User Manual

32 ICE RS26+ / RS32+
OPERATOR MANUAL
BATTERY GROUP
DIA
NO.
PART
NUMBER
DESCRIPTION
NO
REQ'D
1 8320420 USB CHARGE PORT 1
2 8320401 BOX, BATTERY 1
3 8320411 CARGO MESH 1
4 1221410 SCREW, PAN HEAD, M4×10 8
5 1021820 BOLT, HEX HEAD,M8×20 10
6 1422821 SPRING LOCK WASHER, M8 8
7 1421824 FLAT WASHER, M8×
∮
24×2.0 10
8 8320103 SUPPORT, BATTERY, REAR 1
9 8210105 BATTERY, 6V 240AH 4
10 8310135 TRAY, BATTERY 1
11 8310407 PLATE 2
12 8320452 SUPPORT, BATTERY, FRONT 1
13 8320451 FIXED BOARD, BATTERY 1
14 8310736 BATTERY CONNECT CABLE, RED 1
15 8310733 BATTERY CONNECT CABLE, BLACK 1
16 8310737 BATTERY CONNECT CABLE, RED 1
17 8114751
JACKET, BATTERY TERMINAL,BLACK
8
18 8210141 BATTERY CONNECT CABLE, BLACK 3
19 8210114 COVER 1
20 8134061 SCREEN, CHARGER 1

Ice RS26+ Specifications

General

Brand	Ice
Model	RS26+
Category	Scrubber
Language	English
