Ice RS26+ User Manual

34 ICE RS26+ / RS32+
OPERATOR MANUAL
SCRUB HEAD LIFTING GROUP
DIA
NO.
PART
NUMBER
DESCRIPTION
NO
REQ'D
1 8310320 PIN, COTTER 1
2 8210301 PIN,
∮
9.5×38 1
3 8210309 PIN, COTTER 6
4 8310311 PIN,
∮
16×150 1
5 8320129 BUSHING 4
6 8320130 PIN,
∮
16×63 4
7 8310303A LINEAR ACTUATOR, KIT 1
8 8310305 PLATE, ARM, SCRUB HEAD LIFTING 2
9 8310314 FLAT WASHER, LARGE 2
10 1032090 BOLT, HEX HEAD, M10×90 1
11 8310313 PIN,
∮
12×90 1
12 1421030 FLAT WASHER, M10×
∮
30×2.5 4
13 8310304 BRACKET, SCRUB HEAD LIFTING 1
14 1421020 FLAT WASHER, M10×
∮
20×2 2
15 8310307 BUSHING, FLANGE 2
16 1011025 BOLT, HEX HEAD, M10×25 4
17 8310312 PIN,
∮
16×57 2
18 1123012 LOCK NUT, M10 3
19 8310144 SLEEVE,
∮1
6×
∮
18.6×25.4 4
20 8310118 ARM, SCRUB HEAD LIFTING 2
21 8310306 SLEEVE,
∮
10.5×
∮
18.5×34 2
22 8310308 SPRING 1
