Ice RS26+ User Manual

36 ICE RS26+ / RS32+
OPERATOR MANUAL
SCRUB HEAD GROUP
DIA
NO.
PART
NUMBER
DESCRIPTION
NO
REQ'D
1 8320399 BRUSH MOTOR, 24VDC 350W, KIT 2
2 1655025 KEY, 5×5×25 2
3 1021825 BOLT, HEX HEAD, M8×25 4
4 1421824 FLAT WASHER, M8×
∮
24×2.0 18
5 8320307 BRACKET, SCRUB HEAD 2
6 8210532 KNOB, M10 4
7 8340516 KNOB M10 4
8 1113012 LOCK NUT, M10 4
9
8321301 SCRUB HEAD HOUSING, RS26+ 1
8320301 SCRUB HEAD HOUSING, RS32+ 1
10 1123810 LOCK NUT, M8 15
11 8320355 LEVER 4
12 8320358 SLEEVE 4
13 8320351 LEFT BRACKET 1
14 8320352 BRACKET, LEFT SIDE SKIRT 1
15 8320354 BLADE, SIDE SKIRT, LINATEX 2
16 1514616 SCREW, SOCKET HEAD, M6×16 18
17 8320353 CLAMP, SIDE SKIRT 2
18 1512820 BOLT, SOCKET HEAD, M8×20 4
19 1512840 BOLT, SOCKET HEAD, M8×40 4
20 8320357 TORSION SPRING, LEFT ROTATED 2
21 8320356 SLEEVE 4
22 1021080 BOLT, HEX HEAD, M10X80 4
23 1421020 FLAT WASHER, M10×
∮
20×2.0 6
24 1422010 LOCK WASHER, 3/8 6
25 1023010 BOLT, HEX HEAD, 3/8-16×1 6
26 8210804 SPACER 4
27 8210805 HUB, BRUSH DRIVER 2
28 1421828 FLAT WASHER, M8×
∮
28×3.0 2
29 1422821 LOCK WASHER, M8 2
30 1021830 BOLT, HEX HEAD, M8×30 4
31 9000004 CLUCH, G-400S 2
32
9050013 BRUSH, 13 INCH, RS26+ 2
9050016 BRUSH, 16 INCH, RS32+ 2
33 9000003 CENTER LOCK, #3 2
34
9040013 PAD DRIVER, 13 INCH, RS26+ 2
9040016 PAD DRIVER, 16 INCH, RS32+ 2
35
8321302 FRONT SKIRT, RS26+ 1
8320302 FRONT SKIRT, RS32+ 1
36
8321303 FRONT SKIRT CLAMP, RS26+ 1
8320303 RS32+ FRONT SKIRT CLAMP 1
37 8320305 BRACKET, BUMPER WHEEL 1
38 8310362 BUMPER WHEEL 1
39 8115404 SLEEVE,
∮
8×
∮
12.7×12.7 6
40 1022800 BOLT, HEX HEAD, M8×100 1
41 8320362 BRACKET, RIGHT SIDE SKIRT 1
42 8320361 RIGHT BRACKET 1
43 8320363 TORSION SPRING, RIGHT ROTATED 2
44 8320360 RIGHT SIDE SKIRT ASSEMBLY 1
45 8320350 LEFT SIDE SKIRT ASSEMBLY 1
