Ice RS26+ User Manual

ICE RS26+ / RS32+ 41
OPERATOR MANUAL
SOLUTION & DETERGENT SYSTEM
DIA
NO.
PART
NUMBER
DESCRIPTION
NO
REQ'D
1 1221512 SCREW, PAN HEAD, M5×12 4
2 1422513 SPRING LOCK WASHER, M5 4
3 1421510 FLAT WASHER, M5.3×
∮
10×1.0 4
4 8320306 CLAMP 1
5 8310903 TUBING, ID=12MM, L=175MM 1
6 1962025 CLAMP, 16-25MM 8
7 8310374 FITTING, PLASTIC 1
8 8146305 PLASTIC CLAMP 2
9 8310904 TUBING, ID=12MM L=210MM 1
10 8310902 TUBING, ID=16MM L=40MM 1
11 8310376 ELBOW 1
12 8310911 TUBING, ID=16MM L=80MM 1
13 8310375 ELBOW WITH CONNECTOR 1
14 8310901 TUBING, ID=16MM L=500MM 1
15 8310905 TUBING, ID=4MM L=330MM 3
16 1914080 TIE, 3×80MM 10
17 8310467 FITTING 3
18 8310910 TUBING, ID=4MM L=100MM 2
19 1221310 SCREW, PAN HEAD, M3×10 2
20 8320911 BRACKET, PUMP 1
21 8320910K DETERGENT PUMP, KIT 1
22 1123305 LOCK NUT M3 2
23 1421409 FLAT WASHER, M4×
∮
9×0.8 2
24 1422411 LOCK WASHER, M4 2
25 1221412 SCREW, PAN HEAD, M4×12 2
