ICE RS26 / RS28-OB / RS32
6'8:92/9:
952;:/54:'41-85;6
DIA
NO.
PART
NUMBER
DESCRIPTION
NO
REQ'D
1 8310101 SOLUTION TANK 1
2 1221512 SCREW, PAN HEAD, M5×12 2
3 1421510 FLAT WASHER, M5×
ׯ
10×1.0 2
4 8113009 CLAMP, NYLON 2
5 1021820 BOLT, HEX HEAD, M8×20 12
6 1421824 FLAT WASHER, M8×
ׯ
24×2.0 13
7 8310139 PLATE 2
8 8310151A NON-SLIP MAT 2
9 8310132 FOOTREST PLATE 1
10 1222508 SCREW, M5×8 4
11 1512820 SCREW, HEX SOCKET, M8×20 2
12 1421816 FLAT WASHER, M8×
ׯ
16×1.6 2
13 8310140 JUNCTION PLATE 2
14 1422821 LOCK WASHER, M8 8
15
8310130 BRACKET, SOLUTION TANK MNTG 3
16 8310124 ELBOW, G1/2 1
17 8310142 NUT, M36 1
18 8310141 SEALING 2
19 8310238A SENSOR, SOLUTION LEVEL, KIT 1
20 8310125 CAP, SOLUTION TANK 1
21 1021825 BOLT, HEX HEAD, M8×25 1
22 8310225 SLEEVE,
ׯ
8.1×
ׯ
12.7×7.8 1
23 8310224 ARM, RECOVERY TANK SUPPORT 1
24 1962050 CLAMP, 2 INCH 1
25 8011030 HOSE ASSEMBLY 1
26
8310123 ADAPTER, STRAINER ASSY 1
27 8310122 STRAINER ASSY 1
