Ice RS28-OB - Machine Operation

8 ICE RS26 / RS28-OB / RS32
OPERATOR MANUAL
5. For Orbital head model RS28-OB, you need
to attach a rectangular 28in (710mm)
×
14in
(356mm) pad to the Orbital Pad driver, align the
pad to the orbital pad driver, press from to back
and side to side to alignment.
MOUNTING THE SQUEEGEE ASSEMBLY
1. Turn off the 1-Step switch and raise the
6TXHHJHHDVVHPEO\RIIWKHÀRRU
2. Mount the squeegee assembly to the squeegee
pivot bracket. make sure the knobs are
completely seated into the slots before securing
knobs.
3. Connect the Vacuum hose (machine
components, #42) to the squeegee assembly.
Loop the hose by using the hose clip provided.
4. Check the squeegee blades for proper
adjustment.
FILLING THE SOLUTION TANK
7KHPDFKLQHLVHTXLSSHGZLWKD+RVH¿OOSRUW
(machine components, #2) at the side of the
PDFKLQHDQGDEXFNHW¿OOSRUWORFDWHGXQGHUWKH
recovery tank.
NOTE: BeIore accessinJ the bXcNet ¿OOport
make sure that the recovery tank is empty.
:hen ¿OOinJ the soOution tank Zith a bucket
make sure that the bucket is cOean. Do not use
the same bucket Ior ¿OOinJ and draininJ the
machine.
:$51,1*'RQRWSXWDQ\ÀDPPDEOH
materials into solution tank. this can cause an
H[SORVLRQRUD¿UH
FILLING THE DETERGENT BOTTLE
The machine is equipped with a 6 liters Detergent
bottle (machine components, #22). Open the Cap
PDFKLQHFRPSRQHQWV\RXFDQ¿OOGHWHUJHQW
and watch the liquid level on the Detergent level
watching window (machine components, #16).
The ratio of water and detergent is 0~5%, you can
adjust this ratio via pressing the Detergent dosage
adjusting buttons (machine components, #29).
NOTE: OnOy use recommended cOeaninJ
chemicaOs. Contact your ManitoriaO suppOy
distributor for recommendations on proper
chemicaOs.
WARNING: Do not operate machine
unless you have read and understand this
manual.
PRE-OPERATION CHECKS
1. Check the tank cover seals for damage.
2. Drain the recovery tank, check the vacuum fan
LQOHW¿OWHUFOHDQWKHPLIQHFHVVDU\
3. Check the vacuum hose for debris or blockage.
4. Check the squeegees for damage, wear and for
GHÀHFWLRQDGMXVWPHQW
5. Check whether Pad/Bruch is installed properly .
6. Check the brakes and steering for proper
operation.
OPERATION THE MACHINE
1. Sit in the Operator seat, adjusting the seat
to comfortable place by pushing the Seat
adjustment handle (machine components, #14).
NOTE: The machine ZiOO not traveO unOess the
operator is sitting in the operator seat.
2. Turn on the machine.
Check the LED display screen (machine
components, #31) , if there are fault codes
(machine components, #33) and the Fault
indicator (machine components, #32) is blink,
please Do Not operation the machine unless the
faults have been eliminated (please see FAULT
CODES AND ELIMINATE section).
3. Select the preferred settings by pressing the
Brush pressure adjusting buttons (machine
FRPSRQHQWV6ROXWLRQÀRZDGMXVWLQJ
buttons (machine components, #36) and
Detergent dosage adjusting buttons.
NOTE: 8se the minimaO pressure and ÀoZ
as possibOe.
4. Turn on the 1-Step switch, the Scrub head
assembly and the Squeegee assembly will
lower down automatically, all the presetting
functions will turn on.
5. The machine can scrub in both forward and
backward, place the Directional switch (machine
components, #24) in the forward direction is to
move forward, backward is to move backward.
The horn will sound and the squeegee will
raise automatically (the vacuum motor will turn
off after a short delay) when drive machine
backwards. This is to prevents damaging the
squeegee.
NOTE: Go sOoZ Zhen drive machine
backZards.
MACHINE OPERATION
