ICE RS26 / RS28-OB / RS32
6'8:92/9:
('::+8?-85;6
DIA
NO.
PART
NUMBER
DESCRIPTION
NO
REQ'D
1 8310401 BOX, BATTERY 1
2 1021820 BOLT, HEX HEAD, M8×20 8
3 1422821 LOCK WASHER, M8 4
4 1421824 FLAT WASHER, M8×
ׯ
24×2.0 8
5 8310131 SUPPORT, BATTERY, REAR 1
6 8210105 BATTERY, 6V 230AH 4
7 8310135 TRAY, BATTERY 1
8 8310407 PLATE 2
9 8310136 SUPPORT, BATTERY, FRONT 1
10 8310736 BATTERY CONNECT CABLE, RED 1
11 8310737 BATTERY CONNECT CABLE, RED 1
12 8310733 BATTERY CONNECT CABLE, BLACK 1
13 8114751 JACKET, BATTERY TERMINAL,BLACK 8
14 8210141 BATTERY CONNECT CABLE, BLACK 3
15 1221412 SCREW, PAN HEAD, M4×12 4
16 8310406 COVER 1
17 8210114 COVER 1
18 1662316 RIVET, 3.2×16 4
19 8310404 HINGE ASSEMBLY 1
20 1421409 FLAT WASHER, M4×
ׯ
9×0.8 4
21 8310403 COVER 1
