SCRUB HEAD GROUP
DIA
NO.
PART
NUMBER
DESCRIPTION
NO
REQ'D
1
8310399 BRUSH MOTOR, 24VDC 450W, KIT 2
8310316 CARBON BRUSH 4
2 1655025 KEY, 5×5×25 2
3
8311301 SCRUB HEAD HOUSING, RS26 1
8312301 SCRUB HEAD HOUSING, RS28 1
8310301 SCRUB HEAD HOUSING, RS32 1
4 1021830 BOLT, HEX HEAD, M8×30 9
5 1421824 FLAT WASHER, M8×
∮
24×2.0 18
6 8310356 BRACKET, LEFT 1
7 8210532 KNOB, M10 4
8 1123810 LOCK NUT, M8 9
9 8210531 KNOB, M6 10
10 8310355 CLAMP, SIDE SKIRT 2
11
8310365 BLADE, SIDE SKIRT, LINATEX 2
8310366 BLADE, SIDE SKIRT, PU (OPTION) 2
12 8310357 BRACKET, SIDE SKIRT, LEFT 1
13 1421020 FLAT WASHER, M10×
∮
20×2.0 6
14 1422010 LOCK NUT, 3/8 6
15 1023010 BOLT, HEX HEAD, 3/8-16×1 6
16 8210804 SPACER 4
17 8210805 HUB, BRUSH DRIVE 2
18 1421828 FLAT WASHER, M8×
∮
28×3.0 2
19 1422821 LOCK WASHER, M8 2
20 9000004 CLUTCH, G-400S 2
21
9050013 BRUSH, 13 INCH, RS26 2
9050014 BRUSH, 14 INCH, RS28 2
9050016 BRUSH, 16 INCH, RS32 2
22 9000003 CENTER LOCK, #3 2
23
9040013 PAD DRIVER, 13 INCH, RS26 2
9040014 PAD DRIVER, 14 INCH, RS28 2
9040016 PAD DRIVER, 16 INCH, RS32 2
24
8311358 SKIRT, RS26 1
8312358 SKIRT, RS28 1
8310358 SKIRT, RS32 1
25
8311359 CLAMP, SKIRT, RS26 1
8312359 CLAMP, SKIRT, RS28 1
8310359 CLAMP, SKIRT, RS32 1
26 1421618 FLAT WASHER, M6×
∮
18×1.6 7
27 1021616 BOLT, HEX HEAD, M6×16 7
28 8310361 BRACKET, PROTECTIVE WHEEL 1
29 1021840 BOLT, HEX HEAD, M8×40 1
30 8310362 PROTECTIVE WHEEL 1
31 8115404 SLEEVE,
∮
8×
∮
12.7×12.7 6
32 1022800 BOLT, HEX HEAD, M8×100 1
33 8310354 KNOB, M10 4
34 8310351 BRACKET, SIDE SKIRT, RIGHT 1
35 8310353 BRACKET, RIGHT 1
