10
Error Codes for Snow Ball - TOP ROW TURNS RED IF ERROR
Error 1 Ticket Error DISPLAY SHOWS TIC.
Soluon: Rell Tickets! See secon “When “Tic” appears in the display”
Error 2 CF Error ; Compact ash error
Soluon: Reseat Flash card or replace.
Error 3 Ball Gate Closed Error; Game didn’t see the sensor for closed.
Soluon: Check for proper ball gate operaon. See secon “Ball Gate Assembly”
Error 4 Ball Gate Open Error; Game didn’t see the sensor for open.
Soluon: Check for proper ball gate operaon. See secon “Ball Gate Assembly”
Error 5 Top Motor/Switch Error; Top Row switch not seen.
Soluon: Check Clown Reset Bracket sensor.
Error 6 Boom Motor/Switch Error; Boom Row switch not seen.
Soluon: Check Clown Reset Bracket sensor.
To enter Error display mode, please press the UP push buon located on the lower
center door when in aract. To exit this mode, repress the UP push buon .
What does 7L17 displayed mean? TILT!!
The game has a passive infrared sensor (PIR sensor) located in the top of the canopy to detect peo-
ple trying to climb in the game to cheat. When the sensor senses a change in an object’s tempera-
ture (a person), the game will display “TLT” on your score display. There are two ways the game will
behave when this condition occurs depending on what you have set option 19 to. A setting of 0 will
end the current game and allow the player to reinsert money to play again. A setting of 1 will lock the
game in 7L17 mode until the operator cycles power to the game.
Here are some steps to troubleshoot this issue:
Unplug cheat sensor at connector J26 on the main board and coin the game up.
If you can play the game, then the fault is likely the cheat sensor or a short in the harness-
ing. Replacement ICE part number BL1332X.
If you cannot play the game, then contact ICE tech support to have your board sent in for
repair or request an advance replacement.
The pinout for connector J26 are:
Pin 1 is 12-volt DC positive power.
Pin 2 is the cheat signal. 0 volts DC not activated, 12 volts DC activated.
Pin 3 DC ground.
