8.7 CONNECTION OF ELECTRICAL CABLES AND COMPONENTS
TO THE PC BOARD
Observe the connection with the colors of electric cables.
8.8 CLEANING KIT
• The kit is composed of a plastic bottle with rubber pipe, one con
fection of acid citric 1 kg., and instructions for the cleaning proce
dure.
Float level sensor
Micro tip
Cumun micro
Micro defrost
Probe deposit ice
Condenser probe
Blue
Brown
Orange
Black
White
Red
Dip. Switch
to set the
maintenance hours
To Next Page
