PANEL DESCRIPTION
must be set in advance. NOTE: If GPS data is interrupted for 30 sec. the “GPS” indi-
cation disappears. The terminal unit retains the most recent
data in such cases.
■ Function display
q GPS INDICATOR
➥ “GPS” appears while GPS receiver is connected.
➥ “GPS’ disappears when no GPS receiver is connected.
➥ “MNL’ appears when the time data and position data are
input manually.
w TIME ZONE INDICATOR
➥ “Local” appears when the offset time data on the ‘Set-up’
menu is entered.
➥ “No time data’ appears when no GPS receiver is con-
nected and no time data is input manually.
e POSITION INDICATOR
➥ Shows the GPS position data.
• “??” may blinks every 2 sec. instead of position data,
when the GPS position data is invalid. In such a case, the
last position data is held up to 23.5 hours.
➥ Shows the manually input position data when no GPS re-
ceiver is connected. “MNL” appears instead of “GPS” at q.
• “??” may blink every 2 sec. instead of position data, 4
