SECTION 2
.
INSIDE VIEWS
• LOGIC UNIT
CPU
(IC1)
EEPROM
(IC5)
CPU CLOCK
(X1)
SHIFT REGISTER
(IC30)
ANALOG SWITCH
(IC6)
AF LPF/HPF
(IC3)
SHIFT REGISTER
(IC29)
ANALOG SWITCH
(IC28)
