Icom IC-F111 - 3 Connection and Maintenance; Rear Panel and Connection

Optional cable
(OPC-617)
Antenna
+
red:
black:
12V
Battery
e
r
t
w
To the antenna
connector
q
Solder
Crimp
NOTE: Use the terminals
as shown below for the
cable connections.
R WARNING! NEVER re-
move the fuse-holder from
the DC power cable.
R WARNING! NEVER con-
nect to a 24 V battery.
Optional speaker
(SP-22)
■ Rear panel and connection
11
3
CONNECTION AND MAINTENANCE
