Icom IC-F1610 Service Manual

[MAIN UNIT][MAIN UNIT]
S.=Surface mount
R116 7030003340 S.RESISTOR ERJ3GEYJ 151 V (150 Ω)
R117 7030003470 S.RESISTOR ERJ3GEYJ 182 V (1.8 kΩ)
R118 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R119 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R120 7030003550 S.RESISTOR ERJ3GEYJ 822 V (8.2 kΩ)
R121 7030003530 S.RESISTOR ERJ3GEYJ 562 V (5.6 kΩ)
R122 7030003230 S.RESISTOR ERJ3GEYJ 180 V (18 Ω)
R123 7030003370 S.RESISTOR ERJ3GEYJ 271 V (270 Ω)
R124 7030003370 S.RESISTOR ERJ3GEYJ 271 V (270 Ω)
R125 7030003420 S.RESISTOR ERJ3GEYJ 681 V (680 Ω)
R126 7030003540 S.RESISTOR ERJ3GEYJ 682 V (6.8 kΩ)
R127 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R128 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω)
R129 7030003550 S.RESISTOR ERJ3GEYJ 822 V (8.2 kΩ)
R130 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R131 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R132 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R133 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R134 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R135 7030003530 S.RESISTOR ERJ3GEYJ 562 V (5.6 kΩ)
R136 7030004040 S.RESISTOR ERJ3GEYJ 4R7 V (4.7 Ω)
R137 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R138 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R139 7030003530 S.RESISTOR ERJ3GEYJ 562 V (5.6 kΩ)
R140 7030004040 S.RESISTOR ERJ3GEYJ 4R7 V (4.7 Ω)
R141 7030003430 S.RESISTOR ERJ3GEYJ 821 V (820 Ω)
R142 7510000780 S.THERMISTOR NTCCF2012 3SH 333KC-T
R143 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R145 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R146 7030003280 S.RESISTOR ERJ3GEYJ 470 V (47 Ω)
R147 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R148 7030003280 S.RESISTOR ERJ3GEYJ 470 V (47 Ω)
R150 7030003740 S.RESISTOR ERJ3GEYJ 334 V (330 kΩ)
R151 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R152 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R153 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R154 7030003420 S.RESISTOR ERJ3GEYJ 681 V (680 Ω)
R155 7030003500 S.RESISTOR ERJ3GEYJ 332 V (3.3 kΩ)
R156 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R157 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R158 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R159 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R160 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R162 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω)
R163 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R169 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R170 7030003550 S.RESISTOR ERJ3GEYJ 822 V (8.2 kΩ)
R171 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R172 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R173 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R184 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R185 7030003590 S.RESISTOR ERJ3GEYJ 183 V (18 kΩ)
R186 7030003430 S.RESISTOR ERJ3GEYJ 821 V (820 Ω)
R187 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R188 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 kΩ)
R189 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R190 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R191 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R192 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R193 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R194 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R195 7030003880 S.RESISTOR ERJ3GEYJ 244 V (240 kΩ)
R196 7030003610 S.RESISTOR ERJ3GEYJ 273 V (27 kΩ)
R197 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ)
R208 7030000460 S.RESISTOR MCR10EZHJ 4.7 kΩ (472)
R209 7030000460 S.RESISTOR MCR10EZHJ 4.7 kΩ (472)
R210 7030000460 S.RESISTOR MCR10EZHJ 4.7 kΩ (472)
R211 7030000460 S.RESISTOR MCR10EZHJ 4.7 kΩ (472)
R212 7030000460 S.RESISTOR MCR10EZHJ 4.7 kΩ (472)
R213 7030000460 S.RESISTOR MCR10EZHJ 4.7 kΩ (472)
R215 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R216 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R217 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R218 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R222 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R224 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R228 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R230 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R231 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R232 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R238 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R239 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R240 7030003660 S.RESISTOR ERJ3GEYJ 683 V (68 kΩ)
R242 7030003500 S.RESISTOR ERJ3GEYJ 332 V (3.3 kΩ)
R243 7030003460 S.RESISTOR ERJ3GEYJ 152 V (1.5 kΩ)
R244 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R245 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R246 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R247 7030003700 S.RESISTOR ERJ3GEYJ 154 V (150 kΩ)
R248 7030003700 S.RESISTOR ERJ3GEYJ 154 V (150 kΩ)
R249 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R250 7030003670 S.RESISTOR ERJ3GEYJ 823 V (82 kΩ)
R251 7030003410 S.RESISTOR ERJ3GEYJ 561 V (560 Ω)
R255 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R256 7030003750 S.RESISTOR ERJ3GEYJ 394 V (390 kΩ)
R257 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R258 7030003570 S.RESISTOR ERJ3GEYJ 123 V (12 kΩ)
R259 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R260 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R261 7030003760 S.RESISTOR ERJ3GEYJ 474 V (470 kΩ)
R262 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R263 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R267 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R268 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R269 7030003760 S.RESISTOR ERJ3GEYJ 474 V (470 kΩ)
R270 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R271 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R272 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R273 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R275 7410000950 S.ARRAY EXB-V8V 102JV
R276 7410000950 S.ARRAY EXB-V8V 102JV
R277 7410000950 S.ARRAY EXB-V8V 102JV
R278 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R281 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R283 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R284 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R285 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R291 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R292 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R293 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R294 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R295 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R296 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R297 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R298 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R299 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R300 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ)
R301 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R302 7030003570 S.RESISTOR ERJ3GEYJ 123 V (12 kΩ)
R303 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R304 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R305 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R306 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R307 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R308 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R309 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R310 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R312 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R313 7030003730 S.RESISTOR ERJ3GEYJ 274 V (270 kΩ)
R314 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R315 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R316 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R317 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ)
R319 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R320 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R321 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R322 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R323 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R324 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R325 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R326 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R327 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R328 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R329 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R330 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R331 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R333 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R335 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R336 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R337 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R338 7030003650 S.RESISTOR ERJ3GEYJ 563 V (56 kΩ)
R339 7030003610 S.RESISTOR ERJ3GEYJ 273 V (27 kΩ)
R340 7030003370 S.RESISTOR ERJ3GEYJ 271 V (270 Ω)
R341 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
6 - 4
REF ORDER
DESCRIPTION
NO. NO.
REF ORDER
DESCRIPTION
NO. NO.
