Icom IC-F1610 Service Manual

[MAIN UNIT][MAIN UNIT]
S.=Surface mount
R342 7030003660 S.RESISTOR ERJ3GEYJ 683 V (68 kΩ)
R344 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R348 7030003510 S.RESISTOR ERJ3GEYJ 392 V (3.9 kΩ)
R349 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R357 7030003760 S.RESISTOR ERJ3GEYJ 474 V (470 kΩ)
R359 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R360 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R361 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R362 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R363 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R365 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω)
R366 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R369 7510000920 S.THERMISTOR NTCCF2012 4CH 104KC-T
R370 7030003550 S.RESISTOR ERJ3GEYJ 822 V (8.2 kΩ)
R371 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R372 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R373 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R374 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ)
R375 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R376 7310003590 S.TRIMMER EVM-1XSX50 B24 (203)
R377 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R378 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R379 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R380 7030003670 S.RESISTOR ERJ3GEYJ 823 V (82 kΩ)
R381 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R382 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R385 7030003430 S.RESISTOR ERJ3GEYJ 821 V (820 Ω)
R386 7030000180 S.RESISTOR MCR10EZHJ 22 Ω (220)
R387 7030003450 S.RESISTOR ERJ3GEYJ 122 V (1.2 kΩ)
R388 7510000860 S.THERMISTOR NTCCF2012 3FH 222KC-T
R389 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R392 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R397 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R398 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R400 7030003750 S.RESISTOR ERJ3GEYJ 394 V (390 kΩ)
R401 7030003710 S.RESISTOR ERJ3GEYJ 184 V (180 kΩ)
R402 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R403 7030004040 S.RESISTOR ERJ3GEYJ 4R7 V (4.7 Ω)
R404 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R405 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R406 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ)
R407 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R408 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R409 7030003460 S.RESISTOR ERJ3GEYJ 152 V (1.5 kΩ)
R410 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R412 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R415 7030000620 S.RESISTOR MCR10EZHJ 100 kΩ (104)
R418 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R420 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 kΩ)
R421 7030004050 S.RESISTOR ERJ3GEYJ 1R0 V (1 Ω)
R501 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R502 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 kΩ)
R503 7030003570 S.RESISTOR ERJ3GEYJ 123 V (12 kΩ)
R504 7030003570 S.RESISTOR ERJ3GEYJ 123 V (12 kΩ)
R505 7030003570 S.RESISTOR ERJ3GEYJ 123 V (12 kΩ)
R506 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 kΩ)
R508 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R509 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R510 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R511 7030003710 S.RESISTOR ERJ3GEYJ 184 V (180 kΩ)
R512 7030003510 S.RESISTOR ERJ3GEYJ 392 V (3.9 kΩ)
R513 7030003650 S.RESISTOR ERJ3GEYJ 563 V (56 kΩ)
R514 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R515 7030003630 S.RESISTOR ERJ3GEYJ 393 V (39 kΩ)
R516 7030003570 S.RESISTOR ERJ3GEYJ 123 V (12 kΩ)
R517 7030003570 S.RESISTOR ERJ3GEYJ 123 V (12 kΩ)
R518 7030003570 S.RESISTOR ERJ3GEYJ 123 V (12 kΩ)
R519 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R520 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R521 7030003710 S.RESISTOR ERJ3GEYJ 184 V (180 kΩ)
R522 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R523 7030003650 S.RESISTOR ERJ3GEYJ 563 V (56 kΩ)
R524 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R525 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R526 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R527 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R528 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R529 7030003750 S.RESISTOR ERJ3GEYJ 394 V (390 kΩ)
R530 7030003500 S.RESISTOR ERJ3GEYJ 332 V (3.3 kΩ)
R531 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R532 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R533 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R534 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R535 7410000950 S.ARRAY EXB-V8V 102JV
R538 7410000950 S.ARRAY EXB-V8V 102JV
R540 7030004360 S.RESISTOR ERJ3EKF 5901 V (5.9 kΩ)
R541 7030004370 S.RESISTOR ERJ3EKF 8251 V (8.25 kΩ)
R542 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R543 7030003420 S.RESISTOR ERJ3GEYJ 681 V (680 Ω)
R544 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R545 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R546 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R547 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R548 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R549 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R550 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R551 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R552 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R553 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R554 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R555 7030005650 S.RESISTOR RR0816R-304-D (300 kΩ)
R556 7030005870 S.RESISTOR RR0816R-104-D (100 kΩ)
R558 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R559 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R560 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R561 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R562 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R563 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R564 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R565 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R566 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R567 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R568 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R569 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R570 7410000950 S.ARRAY EXB-V8V 102JV
R571 7410000950 S.ARRAY EXB-V8V 102JV
R572 7410000950 S.ARRAY EXB-V8V 102JV
R573 7410000950 S.ARRAY EXB-V8V 102JV
R574 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R575 7410000950 S.ARRAY EXB-V8V 102JV
R576 7410000950 S.ARRAY EXB-V8V 102JV
R577 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R578 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R579 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R580 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R581 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R583 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R584 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R585 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R586 7030003540 S.RESISTOR ERJ3GEYJ 682 V (6.8 kΩ)
R587 7030003540 S.RESISTOR ERJ3GEYJ 682 V (6.8 kΩ)
R588 7030003430 S.RESISTOR ERJ3GEYJ 821 V (820 Ω)
R589 7030003610 S.RESISTOR ERJ3GEYJ 273 V (27 kΩ)
R590 7030003880 S.RESISTOR ERJ3GEYJ 244 V (240 kΩ)
R591 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R592 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R593 7030003590 S.RESISTOR ERJ3GEYJ 183 V (18 kΩ)
R594 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R595 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R596 7030003650 S.RESISTOR ERJ3GEYJ 563 V (56 kΩ)
C2 4030011160 S.CERAMIC GRM42-6 CH 150J 500PT
C3 4030011210 S.CERAMIC GRM42-6 CH 330J 500PT
C4 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C5 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C6 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C7 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C8 4030011210 S.CERAMIC GRM42-6 CH 330J 500PT
C9 4030011080 S.CERAMIC GRM42-6 CH 060D 500PT
C10 4030011170 S.CERAMIC GRM42-6 CH 180J 500PT
C11 4030011240 S.CERAMIC GRM42-6 CH 470J 500PT
C13 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C14 4510004650 S.ELECTROLYTIC ECEV1EA4R7SR
C15 4030011160 S.CERAMIC GRM42-6 CH 150J 500PT
C16 4030011160 S.CERAMIC GRM42-6 CH 150J 500PT
C17 4030011180 S.CERAMIC GRM42-6 CH 220J 500PT
C18 4030007030 S.CERAMIC C1608 CH 1H 150J-T-A
C19 4030009530 S.CERAMIC C1608 CH 1H 030B-T-A
C20 4030009530 S.CERAMIC C1608 CH 1H 030B-T-A
C21 4030009520 S.CERAMIC C1608 CH 1H 020B-T-A
C22 4030007060 S.CERAMIC C1608 CH 1H 270J-T-A
C23 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C26 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
6 - 5
REF ORDER
DESCRIPTION
NO. NO.
REF ORDER
DESCRIPTION
NO. NO.
