Icom IC-F1610 Service Manual

[MAIN UNIT][MAIN UNIT]
S.=Surface mount
C27 4030011770 S.CERAMIC C1608 CH 1H 060B-T-A
C28 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C29 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C30 4030007060 S.CERAMIC C1608 CH 1H 270J-T-A
C31 4030009520 S.CERAMIC C1608 CH 1H 020B-T-A
C32 4030008560 S.CERAMIC C1608 CH 1H 300J-T-A
C33 4030011770 S.CERAMIC C1608 CH 1H 060B-T-A
C34 4030009520 S.CERAMIC C1608 CH 1H 020B-T-A
C35 4030009530 S.CERAMIC C1608 CH 1H 030B-T-A
C36 4030011770 S.CERAMIC C1608 CH 1H 060B-T-A
C37 4030008560 S.CERAMIC C1608 CH 1H 300J-T-A
C39 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C40 4030006980 S.CERAMIC C1608 CH 1H 070D-T-A
C41 4030007030 S.CERAMIC C1608 CH 1H 150J-T-A
C42 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C43 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C44 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C45 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C46 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C47 4030009550 S.CERAMIC C1608 CH 1H 2R5B-T-A
C48 4550002890 S.TANTALUM TESVA 1A 225M1-8L
C49 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C50 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C51 4030007110 S.CERAMIC C1608 CH 1H 680J-T-A
C52 4030007140 S.CERAMIC C1608 CH 1H 121J-T-A
C53 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C54 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C55 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C56 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C57 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C58 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C59 4030007110 S.CERAMIC C1608 CH 1H 680J-T-A
C60 4030012600 S.CERAMIC C2012 JB 1A 105M-T-A
C61 4550002890 S.TANTALUM TESVA 1A 225M1-8L
C62 4030007150 S.CERAMIC C1608 CH 1H 151J-T-A
C63 4030007150 S.CERAMIC C1608 CH 1H 151J-T-A
C64 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C65 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C66 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C67 4030008920 S.CERAMIC C1608 JB 1C 473K-T-A
C68 4030008920 S.CERAMIC C1608 JB 1C 473K-T-A
C69 4030008920 S.CERAMIC C1608 JB 1C 473K-T-A
C70 4030008920 S.CERAMIC C1608 JB 1C 473K-T-A
C71 4030008920 S.CERAMIC C1608 JB 1C 473K-T-A
C72 4550002890 S.TANTALUM TESVA 1A 225M1-8L
C73 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C74 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C75 4550000460 S.TANTALUM TESVA 1C 105M1-8L
C83 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C84 4550002890 S.TANTALUM TESVA 1A 225M1-8L
C85 4030008630 S.CERAMIC C1608 JF 1C 104Z-T-A
C86 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C87 4550002890 S.TANTALUM TESVA 1A 225M1-8L
C90 4550006250 S.TANTALUM TEMSVA 1A 106M-8L
C91 4030006870 S.CERAMIC C1608 JB 1H 222K-T-A
C92 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C93 4510005290 S.ELECTROLYTIC ECEV1EA221P
C94 4510006260 S.ELECTROLYTIC ECEV1AA471UP
C95 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C97 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C98 4550002890 S.TANTALUM TESVA 1A 225M1-8L
C100 4030010240 S.CERAMIC C1608 JB 1H 391K-T-A
C101 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C102 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C103 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C104 4550002890 S.TANTALUM TESVA 1A 225M1-8L
C105 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C106 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C107 4550003170 S.TANTALUM TEMSVA 1D 155M-8L
C108 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C112 4550003220 S.TANTALUM TEMSVA 1E 105M-8L
C115 4510004510 ELECTROLYTIC 25 MV 470 HC
C116 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C117 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C118 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C119 4510005750 S.ELECTROLYTIC ECEV1EA220SP
C121 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C122 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C123 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C124 4510005750 S.ELECTROLYTIC ECEV1EA220SP
C125 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C126 4030007020 S.CERAMIC C1608 CH 1H 120J-T-A
C127 4030007060 S.CERAMIC C1608 CH 1H 270J-T-A
C128 4030007020 S.CERAMIC C1608 CH 1H 120J-T-A
C129 4030007070 S.CERAMIC C1608 CH 1H 330J-T-A
C130 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C131 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C132 4030007050 S.CERAMIC C1608 CH 1H 220J-T-A
C133 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C134 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C135 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C136 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C137 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C138 4030007030 S.CERAMIC C1608 CH 1H 150J-T-A
C139 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C140 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C141 4030007010 S.CERAMIC C1608 CH 1H 100D-T-A
C142 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C143 4030007060 S.CERAMIC C1608 CH 1H 270J-T-A
C144 4030007060 S.CERAMIC C1608 CH 1H 270J-T-A
C145 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C146 4030007060 S.CERAMIC C1608 CH 1H 270J-T-A
C147 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C148 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C149 4030007040 S.CERAMIC C1608 CH 1H 180J-T-A
C150 4030007010 S.CERAMIC C1608 CH 1H 100D-T-A
C151 4030007010 S.CERAMIC C1608 CH 1H 100D-T-A
C152 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C153 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C154 4550006250 S.TANTALUM TEMSVA 1A 106M-8L
C155 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C156 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C157 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C158 4030009500 S.CERAMIC C1608 CH 1H 0R5B-T-A
C159 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C160 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C161 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C162 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C163 4030009500 S.CERAMIC C1608 CH 1H 0R5B-T-A
C164 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C165 4030007010 S.CERAMIC C1608 CH 1H 100D-T-A
C166 4030007010 S.CERAMIC C1608 CH 1H 100D-T-A
C167 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C168 4030007070 S.CERAMIC C1608 CH 1H 330J-T-A
C169 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C170 4030009650 S.CERAMIC C1608 CH 1H 240J-T-A
C171 4030007000 S.CERAMIC C1608 CH 1H 090D-T-A
C172 4030007010 S.CERAMIC C1608 CH 1H 100D-T-A
C173 4030007110 S.CERAMIC C1608 CH 1H 680J-T-A
C174 4030008180 S.CERAMIC C1608 UJ 1H 030C-T-A
C176 4030007070 S.CERAMIC C1608 CH 1H 330J-T-A
C177 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C178 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C179 4550000550 S.TANTALUM TESVA 1V 224M1-8L
C181 4550003220 S.TANTALUM TEMSVA 1E 105M-8L
C182 4510004650 S.ELECTROLYTIC ECEV1EA4R7SR
C183 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C184 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C185 4550002890 S.TANTALUM TESVA 1A 225M1-8L
C186 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C187 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C191 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C197 4550006250 S.TANTALUM TEMSVA 1A 106M-8L
C200 4550002890 S.TANTALUM TESVA 1A 225M1-8L
C201 4030008630 S.CERAMIC C1608 JF 1C 104Z-T-A
C202 4030006870 S.CERAMIC C1608 JB 1H 222K-T-A
C203 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C204 4550003220 S.TANTALUM TEMSVA 1E 105M-8L
C205 4030004760 S.CERAMIC C2012 JF 1E 104Z-T-A
C206 4510005290 S.ELECTROLYTIC ECEV1EA221P
C207 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C208 4550000460 S.TANTALUM TESVA 1C 105M1-8L
C209 4550005980 S.TANTALUM TEMSVA 1A 475M-8L
C210 4550000460 S.TANTALUM TESVA 1C 105M1-8L
C211 4550000460 S.TANTALUM TESVA 1C 105M1-8L
C212 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C214 4550006250 S.TANTALUM TEMSVA 1A 106M-8L
C216 4030007050 S.CERAMIC C1608 CH 1H 220J-T-A
C217 4030006980 S.CERAMIC C1608 CH 1H 070D-T-A
C218 4030012600 S.CERAMIC C2012 JB 1A 105M-T-A
C224 4030008920 S.CERAMIC C1608 JB 1C 473K-T-A
C225 4030011330 S.CERAMIC C1608 CH 1H 391J-T-A
C226 4550003220 S.TANTALUM TEMSVA 1E 105M-8L
C228 4030009880 S.CERAMIC C1608 JB 1H 682K-T-A
6 - 6
REF ORDER
DESCRIPTION
NO. NO.
REF ORDER
DESCRIPTION
NO. NO.
