[MAIN UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
Q32 1590001190 S.TR XP6501-(TX) .AB T 104.4/72.6
Q33 1590001450 S.FET 2SJ144-GR (TE85R) B 148.5/21.6
Q34 1540000550 S.TR 2SD1664 T100Q B 101.2/81.2
Q35 1590001050 S.TR DTC114TUA T106 T 104.4/76.2
Q36 1530002850 S.TR 2SC4116-BL (TE85R)
[F2721/D], [F2821/D] only T 48.3/84.1
Q38 1590000430 S.TR DTC144EUA T106 T 148.6/30.8
Q39 1590000430 S.TR DTC144EUA T106 T 148.6/33.4
Q40 1590000430 S.TR DTC144EUA T106 B 142/41.1
Q41 1590000430 S.TR DTC144EUA T106 B 126/79.9
Q42 1550000100 S.FET 2SJ377 (TE16L1NQ) B 131.5/75.6
Q43 1590000430 S.TR DTC144EUA T106 B 87.8/65.3
Q44 1590000990 S.TR DTC363EK T146 B 145/38.1
Q45 1590000430 S.TR DTC144EUA T106 T 22.4/28.1
Q46 1530002850 S.TR 2SC4116-BL (TE85R) B 79/57.1
Q47 1530002850 S.TR 2SC4116-BL (TE85R) B 81.5/57.1
Q48 1530000370 S.TR 2SC3356-T1B B 69/92.8
Q49 1590001400 S.TR XP1214 (TX) B 67.4/48.4
Q50 1560000530 S.FET 2SK880-GR (TE85R) B 75.4/57.1
Q51 1560001360 S.FET 2SK3019 TL B 41.3/45.3
Q52 1560001360 S.FET 2SK3019 TL B 66.4/34.1
Q53 1560001360 S.FET 2SK3019 TL B 66.8/19.4
Q54 1590001650 S.TR XP4601 (TX) B 74/42.5
Q55 1590000430 S.TR DTC144EUA T106 B 78.8/42.5
Q56 1560001360 S.FET 2SK3019 TL B 62.7/22.6
D2 1790001260 S.DIO MA2S077-(TX) T 28.2/16.3
D3 1790001260 S.DIO MA2S077-(TX) T 28.2/17.8
D4 1790001260 S.DIO MA2S077-(TX) T 25.9/21.9
D5 1790001260 S.DIO MA2S077-(TX) T 27.2/21.9
D7 1750001150 S.VCP HVC383BTRF-E T 43.6/52.4
D9 1750001150 S.VCP HVC383BTRF-E T 43.6/48
D11 1750000710 S.VCP HVC350BTRF T 45.7/53.5
D12 1720000570 S.VCP MA368 (TX) T 68.5/50.8
D13 1750000710 S.VCP HVC350BTRF T 45.7/46.9
D14 1750000520 S.DIO DAN222TL B 110.8/68.3
D15 1790000620 S.DIO MA77 (TX) B 109.9/51.2
D16 1750000430 S.DIO HSB88WSTR T 33.7/65.5
D17 1750000710 S.VCP HVC350BTRF B 23.5/58.8
D18 1750000710 S.VCP HVC350BTRF B 20.7/58.8
D19 1750000580 S.DIO 1SV307 (TPH3) B 59.6/73.4
D20 1790000620 S.DIO MA77 (TX) B 56.9/72.3
D21 1750000520 S.DIO DAN222TL T 67.4/102.6
D22 1790001250 S.DIO MA2S111-(TX) T 17.3/66.5
D23 1750000710 S.VCP HVC350BTRF B 13.7/70.8
D24 1790001250 S.DIO MA2S111-(TX) T 14.6/66.5
D25 1750000370 S.DIO DA221 TL T 17/68.3
D26 1750000710 S.VCP HVC350BTRF B 13.7/75.6
D27 1790000620 S.DIO MA77 (TX) B 24.1/79.7
D28 1790000660 S.DIO MA728 (TX) B 25.9/79.7
D29 1710001060 DIO XB15A407
[F2721/D], [F2821/D] only
D30 1750000510 S.DIO UM9401F [F2710], [F2810] only T 32.3/93
D31 1750000510 S.DIO UM9401F T 37.1/84.9
D34 1790001250 S.DIO MA2S111-(TX) B 145.1/82.5
D35 1790001210 S.DIO 1SS375-TL B 31.8/90.4
D36 1750000520 S.DIO DAN222TL T 128/42.8
D37 1750000370 S.DIO DA221 TL T 104.4/78.5
D38 1790000660 S.DIO MA728 (TX) B 3/86.2
D39 1790001250 S.DIO MA2S111-(TX) B 151.5/22
D40 1790000660 S.DIO MA728 (TX) B 4.4/102.9
D41 1790001240 S.DIO MA2S728-(TX) T 54.6/81.5
D44 1750000520 S.DIO DAN222TL B 89.4/75.9
D46 1790000700 DIO DSA3A1
D47 1750000520 S.DIO DAN222TL B 87.2/75.9
D48 1750000520 S.DIO DAN222TL B 95.4/75.9
D49 1790001250 S.DIO MA2S111-(TX) B 142/38.1
D51 1160000050 S.DIO DAP202U T106 B 139.9/19.3
D52 1160000050 S.DIO DAP202U T106 B 138.5/15.9
D53 1790001250 S.DIO MA2S111-(TX) T 126.1/42.9
D54 1160000050 S.DIO DAP202U T106 T 134.2/13.8
D55 1160000050 S.DIO DAP202U T106 B 140.7/11
D57 1750000370 S.DIO DA221 TL T 113.6/103.8
D58 1750000370 S.DIO DA221 TL T 111/103.8
D59 1750000370 S.DIO DA221 TL T 105.7/103.9
D60 1750000370 S.DIO DA221 TL T 107.8/103.9
D64 1160000050 S.DIO DAP202U T106 B 143.8/11
D65 1790001250 S.DIO MA2S111-(TX) B 138/20.5
D66 1750000370 S.DIO DA221 TL T 130/105
D67 1750000370 S.DIO DA221 TL T 102.9/103.9
D68 1750000710 S.VCP HVC350BTRF B 12.4/75.6
D69 1750000710 S.VCP HVC350BTRF B 12.4/70.8
D70 1750000710 S.VCP HVC350BTRF T 66.9/46.1
D71 1750001150 S.VCP HVC383BTRF-E T 69.6/46.1
FI1 2020001270 CER CFWLB450KE2A-B0
FI2 2020001410 CER CFWLB450KGFA-B0
[MAIN UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
FI3 2020001780 S.CER CFWCA450KEFA-R0
[F2721D], [F2821D] only B 78.8/18.5
FI4 2030000410 S.MLH FL-380 MFT46.3P 46.350 MHz B 34.3/43.2
FI5 2040001440 S.LC NFE31PT152Z1E9L B 85.2/103.6
FI6 2040001440 S.LC NFE31PT152Z1E9L B 85.2/100.3
FI7 2040001440 S.LC NFE31PT152Z1E9L
[F2721/D], [F2821/D] only B 85.2/97
X1 6050011730 S.XTL CR-765 (3.6864 MHz) B 48.3/21.2
X2 6050012050 S.XTL CR-794 (15.3 MHz) B 82.6/42.8
X3 6050009910 S.XTL CR-563 (3.579545 MHz) B 6.7/25.3
X4 6070000190 S.DCR CDBCB450KCAY24-R0 T 30.1/29.6
X5 6050011720 S.XTL CR-764 (19.6608 MHz) B 114.8/55.8
X6 6050012130 S.XTL CR-802 (12.288 MHz)
[F2721D], [F2821D] only B 90.8/27.4
L1 6200004660 S.COL MLF1608A 1R8K-T T 75.8/62.7
L2 6200003540 S.COL MLF1608D R22K-T B 37/29.4
L3 6200004480 S.COL MLF1608D R82K-T B 33.6/27.5
L4 6200005680 S.COL ELJRE 15NG-F B 70.2/59.1
L6 6200004740 S.COL NL 252018T-1R2J B 46.3/52.2
L9 6200004740 S.COL NL 252018T-1R2J B 46.3/48.2
L12 6200008510 S.COL 0.30-0.9-4TR 10.5N [L] only T 48.3/55
L13 6200004740 S.COL NL 252018T-1R2J B 43.8/52.2
L14 6200008510 S.COL 0.30-0.9-4TR 10.5N [L] only T 48.3/45.4
L15 6200004740 S.COL NL 252018T-1R2J B 43.8/48.2
L16 6200003960 S.COL MLF1608A 1R0K-T
[F2721D], [F2821D] only T 101.4/16.4
L17 6200002860 S.COL NL 252018T-4R7J B 29.2/54.8
L18 6200010740 S.COL C2520C-R27G-A B 34.1/55
L19 6200002860 S.COL NL 252018T-4R7J B 45.1/56.9
L20 6200003960 S.COL MLF1608A 1R0K-T
[F2721D], [F2821D] only B 97.3/24.7
L21 6200005720 S.COL ELJRE 33NG-F B 66.5/59.9
L22 6130002960 S.COL 617DB-1327=P3 T 40.1/65.5
L23 6130002960 S.COL 617DB-1327=P3 T 28.4/65.5
L24 6200005690 S.COL ELJRE 18NG-F [H] B 42.8/73
6200005710 S.COL ELJRE 27NG-F [L] B 42.8/73
L25 6200005720 S.COL ELJRE 33NG-F T 60.7/54.3
L26 6200005690 S.COL ELJRE 18NG-F [H] B 45.6/73
6200005710 S.COL ELJRE 27NG-F [L] B 45.6/73
L27 6200005710 S.COL ELJRE 27NG-F B 50.2/68.4
L28 6200007230 S.COL LQW2BHN15NJ01L [L] B 26.3/58.5
6200007670 S.COL LQW2BHN10NJ01L [H] B 26.3/58.5
L29 6200005710 S.COL ELJRE 27NG-F B 59.6/66.5
L30 6200005710 S.COL ELJRE 27NG-F B 64.3/92.7
L31 6200007230 S.COL LQW2BHN15NJ01L [L] B 16.5/63.3
6200007680 S.COL LQW2BHN12NJ01L [H] B 16.5/63.3
L32 6200007690 S.COL LQW2BHN18NJ01L [H] B 16.1/70.9
6200007700 S.COL LQW2BHN22NJ01L [L] B 16.1/70.9
L33 6200005710 S.COL ELJRE 27NG-F B 70.8/94.9
L34 6200005680 S.COL ELJRE 15NG-F T 74.4/100.7
L35 6200010150 S.COL AS080340-15N T 35.6/101
L36 6200007690 S.COL LQW2BHN18NJ01L [H] B 16.1/75.2
6200007700 S.COL LQW2BHN22NJ01L [L] B 16.1/75.2
L37 6200007720 S.COL LQW2BHN33NJ01L B 20.4/79.3
L38 6200010420 S.COL FHW1210HC 1R0JGT B 41.9/93
L39 6200005690 S.COL ELJRE 18NG-F [L] B 28.1/78.6
6200006770 S.COL ELJRE 1N5Z-F [H] B 28.1/78.6
L40 6200010150 S.COL AS080340-15N T 32.3/85.2
L41 6200002860 S.COL NL 252018T-4R7J T 101.3/71.5
L42 6200010150 S.COL AS080340-15N T 24.1/85.4
L43 6200010150 S.COL AS080340-15N T 15.2/86.4
L44 6200010150 S.COL AS080340-15N T 7.5/84.6
L45 6200003960 S.COL MLF1608A 1R0K-T
[F2721D], [F2821D] only T 115.4/20.2
L46 6200004740 S.COL NL 252018T-1R2J B 66.4/45.3
L47 6200004740 S.COL NL 252018T-1R2J B 68.9/45.3
L48 6200008490 S.COL 0.30-0.9-3TR 7.5N T 64.5/45.6
L49 6200010150 S.COL AS080340-15N T 9.5/103.5
L50 6200007850 S.COL ELJNC R82K-F B 49.6/53.8
L51 6200007850 S.COL ELJNC R82K-F B 49.5/46.6
L52 6200004740 S.COL NL 252018T-1R2J [L] B 64.5/49.1
6200007850 S.COL ELJNC R82K-F [H] B 64.5/49.1
L53 6200008490 S.COL 0.30-0.9-3TR 7.5N [H] only T 45.9/55.2
L54 6200008490 S.COL 0.30-0.9-3TR 7.5N [H] only T 45.9/45.2
L56 6200005640 S.COL ELJRE 6N8Z-F B 74/96.1
R1 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 75.8/32.6
R2 7030005700 S.RES ERJ2GEJ 274 X (270 k
Ω
) B 79.7/34.2
R3 7030005230 S.RES ERJ2GEJ 334 X (330 k
Ω
) B 65.9/21.7
R4 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) B 64.7/21
R6 7030007350 S.RES ERJ2GEJ 393 X (39 k
Ω
) B 49.6/28.5
R7 7030007350 S.RES ERJ2GEJ 393 X (39 k
Ω
) T 49.2/33.9
R8 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) T 148.5/7.3
R9 7030005210 S.RES ERJ2GEJ 822 X (8.2 k
Ω
) T 50.9/33.9
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
6 - 4
