[MAIN UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
R10 7030005210 S.RES ERJ2GEJ 822 X (8.2 k
Ω
) T 49.2/32.9
R11 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 54.4/26.9
R12 7030007300 S.RES ERJ2GEJ 332 X (3.3 k
Ω
) T 54.1/16.2
R13 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 136.7/15.9
R14 7030005160 S.RES ERJ2GEJ 105 X (1 M
Ω
) T 145.5/16.1
R15 7030005160 S.RES ERJ2GEJ 105 X (1 M
Ω
) T 144.6/16.1
R16 7030005160 S.RES ERJ2GEJ 105 X (1 M
Ω
) T 143.7/16.1
R17 7030005160 S.RES ERJ2GEJ 105 X (1 M
Ω
) T 142.6/17.8
R18 7030005160 S.RES ERJ2GEJ 105 X (1 M
Ω
) T 142.1/12.9
R19 7030005160 S.RES ERJ2GEJ 105 X (1 M
Ω
) T 138.8/18.5
R20 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 140.3/15.9
R21 7030005160 S.RES ERJ2GEJ 105 X (1 M
Ω
) B 80.7/34.2
R22 7030005230 S.RES ERJ2GEJ 334 X (330 k
Ω
) B 82.1/35.4
R23 7410001130 S.ARY EXB28V102JX T 73.5/66.3
R24 7030010040 S.RES ERJ2GE-JPW B 79.7/38
R26 7030005230 S.RES ERJ2GEJ 334 X (330 k
Ω
) B 53.2/30.2
R27 7030008010 S.RES ERJ2GEJ 123 X (12 k
Ω
) B 51.1/28.5
R28 7030005060 S.RES ERJ2GEJ 333 X (33 k
Ω
) B 53.2/28.5
R29 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 62.5/23
R30 7030005600 S.RES ERJ2GEJ 273 X (27 k
Ω
) B 66.7/16.6
R31 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 59.5/23.4
R32 7030008290 S.RES ERJ2GEJ 183 X (18 k
Ω
) T 65.5/16.2
R33 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 143.7/13.3
R34 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 144.6/13.3
R35 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 145.5/13.3
R36 7410001130 S.ARY EXB28V102JX T 72.9/17.5
R37 7030007570 S.RES ERJ2GEJ 122 X (1.2 k
Ω
) B 39.2/27.2
R38 7030007060 S.RES ERJ2GEJ 684X (680 k
Ω
) B 38.2/27.2
R40 7030010040 S.RES ERJ2GE-JPW B 70/36.2
R41 7030005170 S.RES ERJ2GEJ 474 X (470 k
Ω
) T 49.3/22.7
R42 7030005060 S.RES ERJ2GEJ 333 X (33 k
Ω
) T 54.4/24.9
R43 7030005080 S.RES ERJ2GEJ 823 X (82 k
Ω
) T 54.4/25.9
R44 7030005070 S.RES ERJ2GEJ 683 X (68 k
Ω
) T 49.3/20.7
R45 7030005070 S.RES ERJ2GEJ 683 X (68 k
Ω
) T 51.4/20.7
R46 7030005160 S.RES ERJ2GEJ 105 X (1 M
Ω
) B 8.7/21.5
R47 7030005530 S.RES ERJ2GEJ 100 X (10
Ω
) B 7.1/21
R48 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) T 82.3/46.3
R49 7030004970 S.RES ERJ2GEJ 470 X (47
Ω
) B 72.4/58
R50 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) T 28.7/15.1
R53 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 62.9/34.7
R54 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 56.2/24.9
R55 7030007060 S.RES ERJ2GEJ 684X (680 k
Ω
) B 72/32.6
R56 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 111.6/47.5
R57 7510001730 S.TMR ERTJOEP 473J B 85.7/42.7
R58 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 85.7/44.7
R59 7030008290 S.RES ERJ2GEJ 183 X (18 k
Ω
) T 26.7/15.1
R60 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 66.5/35.8
R62 7030005310 S.RES ERJ2GEJ 124 X (120 k
Ω
) B 69/34.2
R67 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
)
[F2721D], [F2821D] only B 85.5/23.1
R68 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
)
[F2721D], [F2821D] only B 83.6/25.1
R69 7030007300 S.RES ERJ2GEJ 332 X (3.3 k
Ω
)
[F2721D], [F2821D] only B 85.5/25.1
R70 7030004970 S.RES ERJ2GEJ 470 X (47
Ω
) T 110.6/47.5
R77 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 80.2/52.8
R79 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 80.2/54.5
R80 7030007280 S.RES ERJ2GEJ 331 X (330
Ω
) B 76.2/54.5
R83 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) B 77.2/54.5
R84 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) T 28.7/19.1
R85 7030004970 S.RES ERJ2GEJ 470 X (47
Ω
) B 31.4/29
R86 7030005030 S.RES ERJ2GEJ 152 X (1.5 k
Ω
) B 31.4/27.1
R87 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) T 28.7/20.1
R88 7030008290 S.RES ERJ2GEJ 183 X (18 k
Ω
) T 25.9/18.1
R89 7030009320 S.RES ERJ2GEJ 4R7 X (4.7
Ω
) T 25.9/20.1
R90 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) B 62.7/25.7
R91 7030007340 S.RES ERJ2GEJ 153 X (15 k
Ω
) B 70.8/21.7
R92 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 71.7/21.7
R93 7030005600 S.RES ERJ2GEJ 273 X (27 k
Ω
) T 112.9/65.8
R94 7030005600 S.RES ERJ2GEJ 273 X (27 k
Ω
) B 135.4/5.3
R95 7030006610 S.RES ERJ2GEJ 394 X (390 k
Ω
) T 118.7/49.5
R96 7030005030 S.RES ERJ2GEJ 152 X (1.5 k
Ω
)
[F2721D], [F2821D] only B 83.6/23.1
R97 7030005220 S.RES ERJ2GEJ 223 X (22 k
Ω
) T 76.9/37.8
R98 7030005080 S.RES ERJ2GEJ 823 X (82 k
Ω
) T 76.9/33.6
R99 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) T 25.8/24.1
R100 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 24/27.3
R101 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
Ω
) B 24/29.3
R103 7030005310 S.RES ERJ2GEJ 124 X (120 k
Ω
) B 22.3/28.3
R104 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) B 20.6/29.3
R105 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) B 24/32
R106 7030008290 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 109/52.9
R107 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) T 111.1/54.6
R108 7030005070 S.RES ERJ2GEJ 683 X (68 k
Ω
) T 118.7/51.2
R109 7030005070 S.RES ERJ2GEJ 683 X (68 k
Ω
) T 118.7/52.9
R110 7030009710 S.RES ERJ2GEJ 203 X (20 k
Ω
)
[F2721D], [F2821D] only T 85.9/14.7
R111 7030009710 S.RES ERJ2GEJ 203 X (20 k
Ω
)
[F2721D], [F2821D] only T 85.9/12.7
[MAIN UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
R112 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
)
[F2721D], [F2821D] only T 82.2/13.7
R113 7030005070 S.RES ERJ2GEJ 683 X (68 k
Ω
)
[F2721D], [F2821D] only T 83.2/17.4
R114 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
)
[F2721D], [F2821D] only T 87.7/12.7
R115 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
)
[F2721D], [F2821D] only T 103.9/42
R116 7030009710 S.RES ERJ2GEJ 203 X (20 k
Ω
)
[F2721D], [F2821D] only T 87.7/14.7
R117 7030008400 S.RES ERJ2GEJ 182 X (1.8 k
Ω
)
[F2721D], [F2821D] only B 85/15.9
R118 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
)
[F2721D], [F2821D] only B 85/14.9
R119 7030005030 S.RES ERJ2GEJ 152 X (1.5 k
Ω
)
[F2721D], [F2821D] only B 85/18.9
R120 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
)
[F2721D], [F2821D] only B 86.1/21.5
R121 7030007340 S.RES ERJ2GEJ 153 X (15 k
Ω
)
[F2721D], [F2821D] only B 89.9/19
R122 7030004970 S.RES ERJ2GEJ 470 X (47
Ω
)
[F2721D], [F2821D] only B 91.9/19
R123 7030009290 S.RES ERJ2GEJ 562 X (5.6 k
Ω
)
[F2721D], [F2821D] only B 87/14.9
R124 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
)
[F2721D], [F2821D] only B 85/16.9
R125 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 76.9/38.8
R126 7030008010 S.RES ERJ2GEJ 123 X (12 k
Ω
) [H] T 76.9/35.8
7030008290 S.RES ERJ2GEJ 183 X (18 k
Ω
) [L] T 76.9/35.8
R127 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
Ω
) B 72.8/54.5
R128 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 42.9/45.4
R129 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 26.2/33.9
R130 7030008400 S.RES ERJ2GEJ 182 X (1.8 k
Ω
) T 24.7/31.3
R131 7030005010 S.RES ERJ2GEJ 681 X (680
Ω
) B 32.5/32.9
R132 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 34.4/36.7
R133 7030007270 S.RES ERJ2GEJ 151 X (150
Ω
) B 36.2/36.7
R134 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 112.6/56.4
R135 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 112.6/58.2
R136 7030005070 S.RES ERJ2GEJ 683 X (68 k
Ω
) T 116.2/56.4
R137 7030005070 S.RES ERJ2GEJ 683 X (68 k
Ω
) T 116.2/58.2
R138 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
)
[F2721D], [F2821D] only T 84.6/20.2
R139 7030005220 S.RES ERJ2GEJ 223 X (22 k
Ω
)
[F2721D], [F2821D] only T 82.2/17.4
R140 7030009290 S.RES ERJ2GEJ 562 X (5.6 k
Ω
)
[F2721D], [F2821D] only T 81.2/17.4
R141 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
)
[F2721D], [F2821D] only B 88.9/11.4
R142 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
)
[F2721D], [F2821D] only B 91.9/11.4
R143 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
)
[F2721D], [F2821D] only B 100.5/40.4
R144 7030007250 S.RES ERJ2GEJ 220 X (22
Ω
)
[F2721D], [F2821D] only B 100.8/17.2
R145 7030005210 S.RES ERJ2GEJ 822 X (8.2 k
Ω
)
[F2721D], [F2821D] only B 95.1/19
R146 7030005210 S.RES ERJ2GEJ 822 X (8.2 k
Ω
)
[F2721D], [F2821D] only B 95.1/20.8
R147 7030006020 S.RES RR0510P-682-D (6.8 k
Ω
) T 50.1/54.6
R148 7030008250 S.RES RR0510P-562-D (5.6 k
Ω
) T 50.1/45.7
R149 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 64.5/45.3
R150 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) T 69.4/48.3
R151 7030005030 S.RES ERJ2GEJ 152 X (1.5 k
Ω
) B 32.5/36.7
R152 7030008280 S.RES ERJ2GEJ 271 X (270
Ω
) B 38/36.7
R154 7030007280 S.RES ERJ2GEJ 331 X (330
Ω
) B 34.1/48.4
R155 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 31.7/49.4
R156 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 113.6/60
R157 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 119.3/60
R158 7030008300 S.RES ERJ2GEJ 184 X (180 k
Ω
) T 95.6/56
R159 7030005720 S.RES ERJ2GEJ 563 X (56 k
Ω
) T 95.6/55
R160 7030005070 S.RES ERJ2GEJ 683 X (68 k
Ω
) T 115.2/60
R161 7030005220 S.RES ERJ2GEJ 223 X (22 k
Ω
) T 119.3/58.2
R162 7030005220 S.RES ERJ2GEJ 223 X (22 k
Ω
) T 95.6/54
R163 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 120.3/58.2
R164 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
)
[F2721D], [F2821D] only B 92.9/20.8
R165 7030007300 S.RES ERJ2GEJ 332 X (3.3 k
Ω
)
[F2721D], [F2821D] only T 81.2/19.2
R166 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
)
[F2721D], [F2821D] only T 82.2/19.2
R167 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
)
[F2721D], [F2821D] only T 97.8/14.2
R168 7030010040 S.RES ERJ2GE-JPW
[F2721D], [F2821D] only T 100.7/15.1
R169 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
)
[F2721D], [F2821D] only T 98.4/38.3
R170 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
)
[F2721D], [F2821D] only T 99.3/44.2
R171 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
)
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
6 - 5
