[MAIN UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[F2721D], [F2821D] only B 97.8/25.9
R172 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
)
[F2721D], [F2821D] only B 116.5/17.7
R173 7030010040 S.RES ERJ2GE-JPW T 48/52.4
R174 7030006020 S.RES RR0510P-682-D (6.8 k
Ω
) T 50.5/53.4
R175 7030006020 S.RES RR0510P-682-D (6.8 k
Ω
) T 50.5/47
R176 7030005010 S.RES ERJ2GEJ 681 X (680
Ω
) [L] B 49/52
7030009280 S.RES ERJ2GE 331X (330
Ω
) [H] B 49/52
R177 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 53.8/48.4
R178 7030010040 S.RES ERJ2GE-JPW T 48/49
R179 7030009280 S.RES ERJ2GE 331 X (330
Ω
) B 49/48.4
R180 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 31.7/52.4
R181 7030005290 S.RES ERJ2GEJ 682 X (6.8 k
Ω
) B 36.3/51.4
R182 7030005530 S.RES ERJ2GEJ 100 X (10
Ω
) B 31.7/53.4
R184 7030007250 S.RES ERJ2GEJ 220 X (22
Ω
) B 42.6/56.9
R185 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 103.7/61.3
R186 7410000830 S.ARY EXB-V4V 103JV (10 k
Ω
) T 104.5/58.9
R187 7030008010 S.RES ERJ2GEJ 123 X (12 k
Ω
) B 107.4/51.3
R188 7030005530 S.RES ERJ2GEJ 100 X (10
Ω
) B 108.8/55
R189 7030008010 S.RES ERJ2GEJ 123 X (12 k
Ω
) B 110.2/49.8
R190 7030008010 S.RES ERJ2GEJ 123 X (12 k
Ω
) B 110.2/48.8
R191 7030005160 S.RES ERJ2GEJ 105 X (1 M
Ω
) B 110.2/54.5
R192 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
)
[F2721D], [F2821D] only T 118.7/39.5
R193 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) B 64.2/62.9
R194 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 66.5/50.2
R195 7030008280 S.RES ERJ2GEJ 271 X (270
Ω
) B 39.9/72.7
R196 7030007250 S.RES ERJ2GEJ 220 X (22
Ω
) B 40.9/72.7
R197 7030008280 S.RES ERJ2GEJ 271 X (270
Ω
) B 42.1/71.5
R198 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 110.4/62.4
R199 7030004970 S.RES ERJ2GEJ 470 X (47
Ω
)
[F2721D], [F2821D] only B 93.9/24.9
R201 7030004970 S.RES ERJ2GEJ 470 X (47
Ω
)
[F2721D], [F2821D] only B 90.5/33.9
R202 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
)
[F2721D], [F2821D] only B 90.5/32.9
R203 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
)
[F2721D], [F2821D] only B 92.3/32.9
R204 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
)
[F2721D], [F2821D] only T 120.8/25.5
R205 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
)
[F2721D], [F2821D] only B 118.2/15.7
R206 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
)
[F2721D], [F2821D] only B 117.9/14.2
R207 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
)
[F2721D], [F2821D] only B 118.3/11.7
R208 7030005310 S.RES ERJ2GEJ 124 X (120 k
Ω
) T 60.7/51.8
R209 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) T 64.5/55.4
R210 7030007260 S.RES ERJ2GEJ 330 X (33
Ω
) B 60.2/61.5
R211 7030005070 S.RES ERJ2GEJ 683 X (68 k
Ω
) B 61.4/64.2
R212 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) B 62.4/57.3
R213 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) [L] B 50.1/74.3
7030005530 S.RES ERJ2GEJ 100 X (10
Ω
) [H] B 50.1/74.3
R214 7030004990 S.RES ERJ2GEJ 221 X (220
Ω
) [L] T 52.4/70
7030007270 S.RES ERJ2GEJ 151 X (150
Ω
) [H] T 52.4/70
R215 7030005210 S.RES ERJ2GEJ 822 X (8.2 k
Ω
) B 50.1/73.3
R217 7030005210 S.RES ERJ2GEJ 822 X (8.2 k
Ω
) B 52.5/71.3
R218 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) B 22.6/56.7
R219 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) B 21.6/56.7
R220 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 21.6/55
R221 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
Ω
)
[F2721D], [F2821D] only B 96.3/35.3
R222 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
)
[F2721D], [F2821D] only T 121.8/25.5
R223 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
)
[F2721D], [F2821D] only T 120.8/19.6
R224 7030009290 S.RES ERJ2GEJ 562 X (5.6 k
Ω
)
[F2721D], [F2821D] only B 117.2/11.6
R225 7030009290 S.RES ERJ2GEJ 562 X (5.6 k
Ω
)
[F2721D], [F2821D] only B 115.4/11.6
R226 7030009290 S.RES ERJ2GEJ 562 X (5.6 k
Ω
)
[F2721D], [F2821D] only B 114.5/10.2
R227 7030009290 S.RES ERJ2GEJ 562 X (5.6 k
Ω
)
[F2721D], [F2821D] only B 114.5/9.2
R228 7030009290 S.RES ERJ2GEJ 562 X (5.6 k
Ω
)
[F2721D], [F2821D] only B 112.8/9.2
R229 7030007300 S.RES ERJ2GEJ 332 X (3.3 k
Ω
)
[F2721D], [F2821D] only B 118.3/9.5
R230 7030007300 S.RES ERJ2GEJ 332 X (3.3 k
Ω
)
[F2721D], [F2821D] only B 116.7/8.7
R231 7030007300 S.RES ERJ2GEJ 332 X (3.3 k
Ω
)
[F2721D], [F2821D] only B 118.4/8.2
R232 7030007300 S.RES ERJ2GEJ 332 X (3.3 k
Ω
)
[F2721D], [F2821D] only B 116.7/7.5
R233 7030007300 S.RES ERJ2GEJ 332 X (3.3 k
Ω
)
[F2721D], [F2821D] only B 118.4/7.1
R234 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
)
[F2721D], [F2821D] only T 119.5/5.9
R235 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
)
[MAIN UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[F2721D], [F2821D] only B 114.5/7.1
R236 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
)
[F2721D], [F2821D] only B 116.2/5.2
R237 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 62.4/64.2
R238 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 63.2/74.5
R239 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 61.4/74.5
R240 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 62.2/90.5
R242 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 62.2/95.1
R244 7030007260 S.RES ERJ2GEJ 330 X (33
Ω
) B 52.5/72.3
R245 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 54.3/73.3
R246 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 52.5/73.3
R247 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) B 60/69.8
R248 7030005600 S.RES ERJ2GEJ 273 X (27 k
Ω
) B 69.6/95.4
R251 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 65.6/90.5
R252 7030005530 S.RES ERJ2GEJ 100 X (10
Ω
) B 16.6/60.7
R253 7030009320 S.RES ERJ2GEJ 4R7 X (4.7
Ω
) T 14.6/60.3
R254 7030005720 S.RES ERJ2GEJ 563 X (56 k
Ω
) B 16.8/68.9
R255 7030005530 S.RES ERJ2GEJ 100 X (10
Ω
) B 18/66.9
R256 7030008290 S.RES ERJ2GEJ 183 X (18 k
Ω
) T 17/62.3
R257 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) [H] B 18/60.7
7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) [L] B 18/60.7
R258 7030005710 S.RES ERJ2GEJ 121 X (120
Ω
) B 12.4/65.9
R259 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 13.4/67.7
R261 7410000750 S.ARY EXB-V4V 104JV (100 k
Ω
) T 102.2/63.3
R262 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 84.9/65.3
R263 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 83.6/65.3
R264 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 98.9/62.4
R268 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
)
[F2721D], [F2821D] only B 126.5/6.1
R269 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
)
[F2721D], [F2821D] only B 125.7/9.7
R270 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
)
[F2721D], [F2821D] only B 128.5/9.8
R271 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
)
[F2721D], [F2821D] only B 128.5/8.7
R272 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
)
[F2721D], [F2821D] only B 128.5/7.8
R273 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
)
[F2721D], [F2821D] only B 125.7/7.7
R275 7030007270 S.RES ERJ2GEJ 151 X (150
Ω
) T 74.8/103.6
R278 7030008400 S.RES ERJ2GEJ 182 X (1.8 k
Ω
) T 14.6/62.3
R279 7030005170 S.RES ERJ2GEJ 474 X (470 k
Ω
) T 14.6/65.3
R280 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 14.6/64.3
R281 7030007280 S.RES ERJ2GEJ 331 X (330
Ω
) T 65.3/97.8
R282 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 13.8/72.7
R283 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 13.8/73.7
R284 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 12/72.7
R285 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 97.1/70.4
R286 7410001140 S.ARY EXB28V104JX T 99.9/52.6
R287 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 91.4/49.4
R288 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 91.2/49.4
R290 7410000830 S.ARY EXB-V4V 103JV (10 k
Ω
)
[F2721D], [F2821D] only T 99.4/25
R291 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
)
[F2721D], [F2821D] only T 98.3/27.4
R292 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
)
[F2721D], [F2821D] only T 98.3/28.4
R293 7030008400 S.RES ERJ2GEJ 182 X (1.8 k
Ω
) T 65.3/100.8
R294 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 65.3/98.8
R295 7030005030 S.RES ERJ2GEJ 152 X (1.5 k
Ω
) T 65.3/101.8
R296 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 28.4/36.4
R297 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) B 27.3/36.4
R298 7030009320 S.RES ERJ2GEJ 4R7 X (4.7
Ω
)
[F2721D], [F2821D] only T 102.8/13.8
R299 7030006070 S.RES ERJ12YJ101U (100
Ω
) B 47.6/93
R300 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 142.9/82.5
R301 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 148.9/19.8
R302 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) T 148.5/5.6
R303 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) B 29.6/89.6
R304 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) T 129.7/43.2
R305 7410001130 S.ARY EXB28V102JX T 106.5/92.6
R306 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) T 148/11.5
R307 7030005160 S.RES ERJ2GEJ 105 X (1 M
Ω
) B 147.2/19.8
R308 7030005220 S.RES ERJ2GEJ 223 X (22 k
Ω
) B 98.1/73.7
R309 7030005220 S.RES ERJ2GEJ 223 X (22 k
Ω
) T 105/74.4
R310 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) B 99.8/77.9
R311 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 101.5/77.9
R312 7030007270 S.RES ERJ2GEJ 222 X (2.2 k
Ω
) T 103.4/74.4
R313 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) B 6.5/86.2
R314 7030005600 S.RES ERJ2GEJ 273 X (27 k
Ω
) [H] B 3.9/84.8
7030007350 S.RES ERJ2GEJ 393 X (39 k
Ω
) [L] B 3.9/84.8
R315 7030000220 S.RES MCR10EZHJ 47
Ω
(470) B 3/88
R316 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) T 52.6/86.4
R317 7030005700 S.RES ERJ2GEJ 274 X (270 k
Ω
) B 34.3/88.6
R318 7030004990 S.RES ERJ2GEJ 221 X (220
Ω
) T 50.2/87.4
R319 7030005070 S.RES ERJ2GEJ 683 X (68 k
Ω
)
[F2721/D], [F2821/D] only T 48.3/88.3
R320 7520000240 S.POS PRF18BC471QB1RB
[F2721/D], [F2821/D] only B 39.4/89.1
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
6 - 6
