Icom IC-F1710 Service Manual

[MAIN UNIT]
REF ORDER
DESCRIPTION M.
H/V
NO. NO.
LOCATION
C337 4030016930 S.CER ECJ0EB1A104K
[F2721D], [F2821D] only T 96.7/29.2
C338 4030016930 S.CER ECJ0EB1A104K
[F2721D], [F2821D] only T 111.7/11
C339 4030016930 S.CER ECJ0EB1A104K
[F2721D], [F2821D] only T 107.2/10.7
C340 4550007080 S.TAN TEESVA 1C 106M8R
[F2721D], [F2821D] only B 101.2/12.8
C341 4550006250 S.TAN TEESVA 1A 106M8L
[F2721D], [F2821D] only T 102.3/21.8
C342 4550007080 S.TAN TEESVA 1C 106M8R
[F2721D], [F2821D] only B 101.2/10.5
C343 4030016930 S.CER ECJ0EB1A104K
[F2721D], [F2821D] only B 105/11
C345 4030011050 S.CER GRM31M3C2H3R0CY21L T 29.9/105.7
C346 4030011050 S.CER GRM31M3C2H3R0CY21L T 29.9/103.1
C347 4510005750 S.ELE ECEV1EA220SP T 60/95.1
C348 4030011020 S.CER GRM31M4C2H1R0CY21L
[F2710-H], [F2810-H] T 29.9/98.9
4030011040 S.CER GRM31M4C2H2R0CY21L
[Other] T 29.9/98.9
C349 4030011020 S.CER GRM31M4C2H1R0CY21L
[F2710-H], [F2810-H] T 29.9/98.9
4030011040 S.CER GRM31M4C2H2R0CY21L
[Other] T 29.9/96.3
4030011050 S.CER GRM31M3C2H3R0CY21L
[2721/D-L], [2821/D-L] T 29.9/96.3
C350 4550000560 S.TAN TEESVA 1V 334M-8L T 69.7/101.6
C351 4030017460 S.CER ECJ0EB1E102K T 71.3/103.5
C352 4030017420 S.CER ECJ0EC1H470J T 72.3/103.5
C353 4030017420 S.CER ECJ0EC1H470J T 47/103.2
C354 4030017460 S.CER ECJ0EB1E102K T 46/103.2
C355 4510005750 S.ELE ECEV1EA220SP T 51/101.3
C356 4030017730 S.CER ECJ0EB1E471K T 45/103.2
C357 4030017420 S.CER ECJ0EC1H470J B 50.3/90.6
C358 4550006250 S.TAN TEESVA 1A 106M8L T 67.4/98.8
C359 4030017590 S.CER ECJ0EC1H070C B 18.4/76.7
C360 4030017460 S.CER ECJ0EB1E102K B 22.3/78.6
C361 4030017390 S.CER ECJ0EC1H180J [H] B 15.6/73.7
4030017410 S.CER ECJ0EC1H240J [L] B 15.6/73.7
C362 4030017460 S.CER ECJ0EB1E102K B 10.6/73.2
C363 4030017600 S.CER ECJ0EC1H080C B 16.6/76.7
C364 4030017510 S.CER ECJ0EC1H680J B 22.3/80
C365 4030016930 S.CER ECJ0EB1A104K B 26.2/36.4
C366 4510004630 S.ELE ECEV1CA100SR T 105.2/67.5
C367 4030016930 S.CER ECJ0EB1A104K
[F2721D], [F2821D] only T 107.2/12.5
C368 4030016930 S.CER ECJ0EB1A104K
[F2721D], [F2821D] only T 102.8/12.1
C369 4550005980 S.TAN TEESVA 1A 475M8L
[F2721D], [F2821D] only T 104.3/16.3
C370 4550005980 S.TAN TEESVA 1A 475M8L
[F2721D], [F2821D] only T 108.6/16.3
C371 4550005980 S.TAN TEESVA 1A 475M8L
[F2721D], [F2821D] only T 106.5/16.3
C372 4030016930 S.CER ECJ0EB1A104K
[F2721D], [F2821D] only B 108/14.6
C373 4030011070 S.CER GRM31M2C2H5R0CY21L T 32.1/89.6
C374 4030017200 S.CER GRM31BR32J102KY01L T 28/89.6
C375 4030011020 S.CER GRM31M4C2H1R0CY21L [H] T 22.5/91.7
4030011050 S.CER GRM31M3C2H3R0CY21L [L] T 22.5/91.7
C376 4030011040 S.CER GRM31M4C2H2R0CY21L T 24.8/91.7
C377 4030017420 S.CER ECJ0EC1H470J B 43.9/90.6
C378 4030017460 S.CER ECJ0EB1E102K B 82.8/95.3
C379 4030017420 S.CER ECJ0EC1H470J B 81.8/95.3
C380 4030017400 S.CER ECJ0EC1H220J B 80.8/95.3
C381 4030017420 S.CER ECJ0EC1H470J B 52.2/99
C382 4030017460 S.CER ECJ0EB1E102K T 65.3/99.8
C383 4030009570 S.CER C1608 CH 1H 0R3B-T B 28.3/89.6
C384 4030017530 S.CER ECJ0EC1H0R5B [H] B 27.5/80.2
4030017350 S.CER ECJ0EC1H020B [L] B 27.5/80.2
C385 4030017380 S.CER ECJ0EC1H050B [H] B 28.8/80.2
4030017600 S.CER ECJ0EC1H080C [L] B 28.8/80.2
C386 4030018900 S.CER ECJ0EB0J474K B 145.5/83.6
C387 4030017460 S.CER ECJ0EB1E102K B 99.8/73.7
C388 4030011040 S.CER GRM31M4C2H2R0CY21L [H] T 19.9/85.6
4030011050 S.CER GRM31M3C2H3R0CY21L [L] T 19.9/85.6
C389 4030011040 S.CER GRM31M4C2H2R0CY21L [H] T 17/91.5
4030011050 S.CER GRM31M3C2H3R0CY21L [L] T 17/91.5
C390 4030017460 S.CER ECJ0EB1E102K B 51.2/99
C391 4030011050 S.CER GRM31M3C2H3R0CY21L [H] T 13.4/91.5
4030011070 S.CER GRM31M2C2H5R0CY21L [L] T 13.4/91.5
C392 4030017460 S.CER ECJ0EB1E102K T 52.6/87.4
C393 4550005980 S.TAN TEESVA 1A 475M8L T 100/75.2
C394 4030016930 S.CER ECJ0EB1A104K T 96.1/77.6
C395 4510004630 S.ELE ECEV1CA100SR T 150.5/17.1
C396 4510004630 S.ELE ECEV1CA100SR T 26.5/53.4
C397 4030017460 S.CER ECJ0EB1E102K T 101.5/76.9
C398 4030017460 S.CER ECJ0EB1E102K B 101.5/73.7
[MAIN UNIT]
REF ORDER
DESCRIPTION M.
H/V
NO. NO.
LOCATION
C399 4510004630 S.ELE ECEV1CA100SR T 114.1/75.8
C400 4030017460 S.CER ECJ0EB1E102K B 110.1/72.2
C401 4030006860 S.CER C1608 JB 1H 102K-T B 8.9/87
C402 4030006980 S.CER C1608 CH 1H 070D-T [L] B 11/87.7
4030007010 S.CER C1608 CH 1H 100D-T [H] B 11/87.7
C403 4030017420 S.CER ECJ0EC1H470J B 2.1/84.8
C404 4030017420 S.CER ECJ0EC1H470J B 32.5/88.6
C405 4030017460 S.CER ECJ0EB1E102K T 50.2/88.3
C406 4030016790 S.CER ECJ0EB1C103K T 50.2/86.4
C407 4030017460 S.CER ECJ0EB1E102K
[F2721/D], [F2821/D] only T 48.3/87.4
C408 4030016930 S.CER ECJ0EB1A104K B 145.5/81.2
C409 4030016930 S.CER ECJ0EB1A104K B 150.5/83.4
C410 4030018860 S.CER ECJ0EB0J105K B 148/80.2
C412 4030016930 S.CER ECJ0EB1A104K B 150.7/41.3
C413 4030017730 S.CER ECJ0EB1E471K B 147.1/33.9
C414 4030016790 S.CER ECJ0EB1C103K B 147.1/32.9
C415 4030016930 S.CER ECJ0EB1A104K B 148.9/33.9
C417 4030016930 S.CER ECJ0EB1A104K B 145.3/35.9
C418 4550003220 S.TAN TEESVA 1E 105M8L B 111.7/101.2
C419 4550003220 S.TAN TEESVA 1E 105M8L B 107.3/104.3
C420 4550003220 S.TAN TEESVA 1E 105M8L T 115.4/99.4
C421 4550003220 S.TAN TEESVA 1E 105M8L B 113.9/101.2
C422 4030017460 S.CER ECJ0EB1E102K T 101.5/78.2
C423 4030016930 S.CER ECJ0EB1A104K B 151.6/24.4
C424 4030016930 S.CER ECJ0EB1A104K T 148.6/23.2
C428 4510004630 S.ELE ECEV1CA100SR T 114.1/71
C429 4510004630 S.ELE ECEV1CA100SR T 114.1/80.6
C430 4030016930 S.CER ECJ0EB1A104K B 125.2/71.1
C431 4030006860 S.CER C1608 JB 1H 102K-T B 10.5/102.9
C432 4030011070 S.CER GRM31M4C2H1R5CY21L
[L] only T 17.8/101.7
C433 4030017460 S.CER ECJ0EB1E102K B 3.5/101.5
C434 4030011810 S.CER C1608 JB 1A 224K-T T 54.6/84.1
C435 4030017420 S.CER ECJ0EC1H470J B 34.3/89.6
C436 4030017490 S.CER C1608 JB 1A 105K-T T 55.9/81.4
C438 4030017780 S.CER ECJ0EB1E472K T 49.3/81.4
C439 4510008030 S.ELE ECEV1EA471P T 143.7/87.5
C440 4510006260 S.ELE ECEV1AA471UP T 152.5/97.5
C442 4030017420 S.CER ECJ0EC1H470J B 148/77.8
C443 4510006220 S.ELE ECEV1CA101UP T 147.3/70.1
C444 4510006220 S.ELE ECEV1CA101UP T 147.3/63
C445 4550006770 S.TAN TEESVD2 1C 476M-12R B 149.1/62.2
C446 4030016930 S.CER ECJ0EB1A104K B 148/73.1
C448 4030017460 S.CER ECJ0EB1E102K B 148/72.1
C452 4030017460 S.CER ECJ0EB1E102K T 149.6/23.2
C453 4030017460 S.CER ECJ0EB1E102K B 151.6/25.4
C454 4030017460 S.CER ECJ0EB1E102K B 124.2/79.4
C455 4030017460 S.CER ECJ0EB1E102K B 151.6/19.8
C457 4030016930 S.CER ECJ0EB1A104K B 126.5/75.5
C458 4550007080 S.TAN TEESVA 1C 106M8R B 138.2/72.5
C459 4510008030 S.ELE ECEV1EA471P T 129.1/76.9
C460 4030016930 S.CER ECJ0EB1A104K T 137/72.5
C461 4030011040 S.CER GRM31M4C2H2R0CY21L [H] T 15.5/105.2
4030011050 S.CER GRM31M3C2H3R0CY21L [L] T 15.5/105.2
C462 4030017460 S.CER ECJ0EB1E102K T 51.3/81.4
C463 4030017420 S.CER ECJ0EC1H470J T 55.6/79.1
C464 4030017460 S.CER ECJ0EB1E102K T 150.4/107.8
C465 4030017460 S.CER ECJ0EB1E102K T 150.4/106.8
C467 4030017420 S.CER ECJ0EC1H470J T 150.4/104.8
C468 4510006240 S.ELE ECEV1CA221P T 136.3/53.1
C469 4030017460 S.CER ECJ0EB1E102K T 141.7/59.6
C470 4510006240 S.ELE ECEV1CA221P T 148.4/45.3
C471 4510005040 ELE 25 MV 1000 HC
C472 4030005110 S.CER C2012 JB 1E 473K-T B 151.5/54.4
C473 4030005110 S.CER C2012 JB 1E 473K-T B 151.5/50.9
C474 4030017420 S.CER ECJ0EC1H470J T 150.6/28.3
C475 4030017420 S.CER ECJ0EC1H470J B 138.4/80.9
C476 4030017460 S.CER ECJ0EB1E102K B 135.2/78.8
C477 4510008030 S.ELE ECEV1EA471P T 115.1/88.4
C478 4030004760 S.CER C2012 JF 1H 104Z-T B 137.5/79.5
C479 4030017460 S.CER ECJ0EB1E102K T 149.7/82.1
C480 4030017420 S.CER ECJ0EC1H470J T 149.7/83.1
C482 4030017460 S.CER ECJ0EB1E102K T 150.6/35.9
C485 4030017460 S.CER ECJ0EB1E102K B 127.4/96.6
C486 4030018900 S.CER ECJ0EB0J474K B 142/36.9
C487 4030016930 S.CER ECJ0EB1A104K T 26.8/24.1
C488 4030018900 S.CER ECJ0EB0J474K B 67/8.3
C489 4030016930 S.CER ECJ0EB1A104K B 67/6.1
C490 4030016930 S.CER ECJ0EB1A104K B 70.3/5.3
C491 4030016930 S.CER ECJ0EB1A104K B 125/54.4
C492 4030017700 S.CER ECJ0EC1H151J B 56.4/16.7
C495 4030017420 S.CER ECJ0EC1H470J T 103.9/106.7
C496 4030017420 S.CER ECJ0EC1H470J T 133.6/106.9
C497 4030017420 S.CER ECJ0EC1H470J T 131.6/106.9
C498 4030017420 S.CER ECJ0EC1H470J T 108.4/106.7
C499 4030017420 S.CER ECJ0EC1H470J T 126/106.9
C500 4030017420 S.CER ECJ0EC1H470J B 125.1/106.2
C501 4030017420 S.CER ECJ0EC1H470J B 122.8/106.2
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
6 - 10
